Creates an OpenGL context, which can be attached to a component. More...

#include <juce_OpenGLContext.h>

Collaboration diagram for juce::OpenGLContext:

[legend]

Classes
struct	AsyncWorker

struct	AsyncWorkerFunctor

class	NativeContext

Public Types
enum	OpenGLVersion { defaultGLVersion = 0, openGL3_2 }
	OpenGL versions, used by setOpenGLVersionRequired(). More...

enum	TextureMagnificationFilter { nearest, linear }
	Texture magnification filters, used by setTextureMagnificationFilter(). More...

Public Member Functions
	OpenGLContext ()

	~OpenGLContext ()
	Destructor. More...

bool	areShadersAvailable () const
	Returns true if shaders can be used in this context. More...

void	attachTo (Component &)
	Attaches the context to a target component. More...

void	copyTexture (const Rectangle< int > &targetClipArea, const Rectangle< int > &anchorPosAndTextureSize, int contextWidth, int contextHeight, bool textureOriginIsBottomLeft)
	Draws the currently selected texture into this context at its original size. More...

void	detach ()
	Detaches the context from its target component and deletes any native resources. More...

template<typename T >
void	executeOnGLThread (T &&functor, bool blockUntilFinished)
	Execute a lambda, function or functor on the OpenGL thread with an active context. More...

ReferenceCountedObject *	getAssociatedObject (const char *name) const
	This retrieves an object that was previously stored with setAssociatedObject(). More...

unsigned int	getFrameBufferID () const noexcept
	If this context is backed by a frame buffer, this returns its ID number, or 0 if the context does not use a framebuffer. More...

size_t	getImageCacheSize () const noexcept
	Returns the amount of GPU memory that the internal cache for Images is allowed to use. More...

void *	getRawContext () const noexcept
	Returns an OS-dependent handle to some kind of underlying OS-provided GL context. More...

double	getRenderingScale () const noexcept
	Returns the scale factor used by the display that is being rendered. More...

int	getSwapInterval () const
	Returns the current swap-sync interval. More...

Component *	getTargetComponent () const noexcept
	Returns the component to which this context is currently attached, or nullptr. More...

bool	isActive () const noexcept
	Returns true if this context is currently active for the calling thread. More...

bool	isAttached () const noexcept
	Returns true if the context is attached to a component and is on-screen. More...

bool	isTextureNpotSupported () const
	Returns true if non-power-of-two textures are supported in this context. More...

bool	makeActive () const noexcept
	Makes this context the currently active one. More...

void	setAssociatedObject (const char name, ReferenceCountedObject newObject)
	Attaches a named object to the context, which will be deleted when the context is destroyed. More...

void	setComponentPaintingEnabled (bool shouldPaintComponent) noexcept
	Enables or disables the use of the GL context to perform 2D rendering of the component to which it is attached. More...

void	setContinuousRepainting (bool shouldContinuouslyRepaint) noexcept
	Enables or disables continuous repainting. More...

void	setImageCacheSize (size_t cacheSizeBytes) noexcept
	Changes the amount of GPU memory that the internal cache for Images is allowed to use. More...

void	setMultisamplingEnabled (bool) noexcept
	Enables multisampling on platforms where this is implemented. More...

void	setNativeSharedContext (void *nativeContextToShareWith) noexcept
	Provides a context with which you'd like this context's resources to be shared. More...

void	setOpenGLVersionRequired (OpenGLVersion) noexcept
	Sets a preference for the version of GL that this context should use, if possible. More...

void	setPixelFormat (const OpenGLPixelFormat &preferredPixelFormat) noexcept
	Sets the pixel format which you'd like to use for the target GL surface. More...

void	setRenderer (OpenGLRenderer *) noexcept
	Gives the context an OpenGLRenderer to use to do the drawing. More...

bool	setSwapInterval (int numFramesPerSwap)
	Sets whether the context checks the vertical sync before swapping. More...

void	setTextureMagnificationFilter (TextureMagnificationFilter magFilterMode) noexcept
	Sets the texture magnification filter. More...

void	swapBuffers ()
	Swaps the buffers (if the context can do this). More...

void	triggerRepaint ()
	Asynchronously causes a repaint to be made. More...

Static Public Member Functions
static void	deactivateCurrentContext ()
	If any context is active on the current thread, this deactivates it. More...

static OpenGLContext *	getContextAttachedTo (Component &component) noexcept
	If the given component has an OpenGLContext attached, then this will return it. More...

static OpenGLContext *	getCurrentContext ()
	Returns the context that's currently in active use by the calling thread, or nullptr if no context is active. More...

Public Attributes
OpenGLExtensionFunctions	extensions
	This structure holds a set of dynamically loaded GL functions for use on this context. More...

Private Member Functions
void	execute (AsyncWorker::Ptr, bool)

CachedImage *	getCachedImage () const noexcept

Private Attributes
std::unique_ptr< Attachment >	attachment

void *	contextToShareWith = nullptr

std::atomic< bool >	continuousRepaint { false }

double	currentRenderScale = 1.0

size_t	imageCacheMaxSize = 8 * 1024 * 1024

NativeContext *	nativeContext = nullptr

OpenGLPixelFormat	openGLPixelFormat

bool	overrideCanAttach = false

bool	renderComponents = true

OpenGLRenderer *	renderer = nullptr

TextureMagnificationFilter	texMagFilter = linear

bool	useMultisampling = false

OpenGLVersion	versionRequired = defaultGLVersion

Friends
class	OpenGLTexture

Detailed Description

Creates an OpenGL context, which can be attached to a component.

To render some OpenGL, you should create an instance of an OpenGLContext, and call attachTo() to make it use a component as its render target.

To provide threaded rendering, you can supply an OpenGLRenderer object that will be used to render each frame.

Before your target component or OpenGLRenderer is deleted, you MUST call detach() or delete the OpenGLContext to allow the background thread to stop and the native resources to be freed safely.

See also: OpenGLRenderer

@tags{OpenGL}

Member Enumeration Documentation

◆ OpenGLVersion

enum juce::OpenGLContext::OpenGLVersion

OpenGL versions, used by setOpenGLVersionRequired().

Enumerator
defaultGLVersion
openGL3_2

◆ TextureMagnificationFilter

enum juce::OpenGLContext::TextureMagnificationFilter

Texture magnification filters, used by setTextureMagnificationFilter().

Enumerator
nearest
linear

Constructor & Destructor Documentation

◆ OpenGLContext()

juce::OpenGLContext::OpenGLContext ( )

◆ ~OpenGLContext()

juce::OpenGLContext::~OpenGLContext ( )

Destructor.

Member Function Documentation

◆ areShadersAvailable()

bool juce::OpenGLContext::areShadersAvailable ( ) const

Returns true if shaders can be used in this context.

◆ attachTo()

void juce::OpenGLContext::attachTo ( Component & )

Attaches the context to a target component.

If the component is not fully visible, this call will wait until the component is shown before actually creating a native context for it.

When a native context is created, a thread is started, and will be used to call the OpenGLRenderer methods. The context will be floated above the target component, and when the target moves, it will track it. If the component is hidden/shown, the context may be deleted and re-created.

◆ copyTexture()

void juce::OpenGLContext::copyTexture	(	const Rectangle< int > &	targetClipArea,
		const Rectangle< int > &	anchorPosAndTextureSize,
		int	contextWidth,
		int	contextHeight,
		bool	textureOriginIsBottomLeft
	)

Draws the currently selected texture into this context at its original size.

Parameters

targetClipArea	the target area to draw into (in top-left origin coords)
anchorPosAndTextureSize	the position of this rectangle is the texture's top-left anchor position in the target space, and the size must be the total size of the texture.
contextWidth	the width of the context or framebuffer that is being drawn into, used for scaling of the coordinates.
contextHeight	the height of the context or framebuffer that is being drawn into, used for vertical flipping of the y coordinates.
textureOriginIsBottomLeft	if true, the texture's origin is treated as being at (0, 0). If false, it is assumed to be (0, 1)

◆ deactivateCurrentContext()

static void juce::OpenGLContext::deactivateCurrentContext ( )

static

If any context is active on the current thread, this deactivates it.

Note that on some platforms, like Android, this isn't possible.

◆ detach()

void juce::OpenGLContext::detach ( )

Detaches the context from its target component and deletes any native resources.

If the context has not been attached, this will do nothing. Otherwise, it will block until the context and its thread have been cleaned up.

◆ execute()

void juce::OpenGLContext::execute	(	AsyncWorker::Ptr	,
		bool
	)

private

◆ executeOnGLThread()

template<typename T >

void juce::OpenGLContext::executeOnGLThread	(	T &&	functor,
		bool	blockUntilFinished
	)

Execute a lambda, function or functor on the OpenGL thread with an active context.

This method will attempt to execute functor on the OpenGL thread. If blockUntilFinished is true then the method will block until the functor has finished executing.

This function can only be called if the context is attached to a component. Otherwise, this function will assert.

This function is useful when you need to execute house-keeping tasks such as allocating, deallocating textures or framebuffers. As such, the functor will execute without locking the message thread. Therefore, it is not intended for any drawing commands or GUI code. Any GUI code should be executed in the OpenGLRenderer::renderOpenGL callback instead.

◆ getAssociatedObject()

ReferenceCountedObject* juce::OpenGLContext::getAssociatedObject ( const char * name ) const

This retrieves an object that was previously stored with setAssociatedObject().

If no object is found with the given name, this will return nullptr. This method must only be called from within the GL rendering methods.

See also: setAssociatedObject

◆ getCachedImage()

CachedImage* juce::OpenGLContext::getCachedImage ( ) const

privatenoexcept

◆ getContextAttachedTo()

static OpenGLContext* juce::OpenGLContext::getContextAttachedTo ( Component & component )

staticnoexcept

If the given component has an OpenGLContext attached, then this will return it.

◆ getCurrentContext()

static OpenGLContext* juce::OpenGLContext::getCurrentContext ( )

static

Returns the context that's currently in active use by the calling thread, or nullptr if no context is active.

◆ getFrameBufferID()

unsigned int juce::OpenGLContext::getFrameBufferID ( ) const

noexcept

If this context is backed by a frame buffer, this returns its ID number, or 0 if the context does not use a framebuffer.

◆ getImageCacheSize()

size_t juce::OpenGLContext::getImageCacheSize ( ) const

noexcept

Returns the amount of GPU memory that the internal cache for Images is allowed to use.

◆ getRawContext()

void* juce::OpenGLContext::getRawContext ( ) const

noexcept

Returns an OS-dependent handle to some kind of underlying OS-provided GL context.

The exact type of the value returned will depend on the OS and may change if the implementation changes. If you want to use this, digging around in the native code is probably the best way to find out what it is.

◆ getRenderingScale()

double juce::OpenGLContext::getRenderingScale ( ) const

inlinenoexcept

Returns the scale factor used by the display that is being rendered.

The scale is that of the display - see Displays::Display::scale

Note that this should only be called during an OpenGLRenderer::renderOpenGL() callback - at other times the value it returns is undefined.

◆ getSwapInterval()

int juce::OpenGLContext::getSwapInterval ( ) const

Returns the current swap-sync interval.

See setSwapInterval() for info about the value returned.

◆ getTargetComponent()

Component* juce::OpenGLContext::getTargetComponent ( ) const

noexcept

Returns the component to which this context is currently attached, or nullptr.

◆ isActive()

bool juce::OpenGLContext::isActive ( ) const

noexcept

Returns true if this context is currently active for the calling thread.

◆ isAttached()

bool juce::OpenGLContext::isAttached ( ) const

noexcept

Returns true if the context is attached to a component and is on-screen.

Note that if you call attachTo() for a non-visible component, this method will return false until the component is made visible.

◆ isTextureNpotSupported()

bool juce::OpenGLContext::isTextureNpotSupported ( ) const

Returns true if non-power-of-two textures are supported in this context.

◆ makeActive()

bool juce::OpenGLContext::makeActive ( ) const

noexcept

Makes this context the currently active one.

You should never need to call this in normal use - the context will already be active when OpenGLRenderer::renderOpenGL() is invoked.

◆ setAssociatedObject()

void juce::OpenGLContext::setAssociatedObject	(	const char *	name,
		ReferenceCountedObject *	newObject
	)

Attaches a named object to the context, which will be deleted when the context is destroyed.

This allows you to store an object which will be released before the context is deleted. The main purpose is for caching GL objects such as shader programs, which will become invalid when the context is deleted.

This method must only be called from within the GL rendering methods.

◆ setComponentPaintingEnabled()

void juce::OpenGLContext::setComponentPaintingEnabled ( bool shouldPaintComponent )

noexcept

Enables or disables the use of the GL context to perform 2D rendering of the component to which it is attached.

If this is false, then only your OpenGLRenderer will be used to perform any rendering. If true, then each time your target's paint() method needs to be called, an OpenGLGraphicsContext will be used to render it, (after calling your OpenGLRenderer if there is one).

By default this is set to true. If you're not using any paint() method functionality and are doing all your rendering in an OpenGLRenderer, you should disable it to improve performance.

Note: This must be called BEFORE attaching your context to a target component!

◆ setContinuousRepainting()

void juce::OpenGLContext::setContinuousRepainting ( bool shouldContinuouslyRepaint )

noexcept

Enables or disables continuous repainting.

If set to true, the context will run a loop, re-rendering itself without waiting for triggerRepaint() to be called, at a frequency determined by the swap interval (see setSwapInterval). If false, then after each render callback, it will wait for another call to triggerRepaint() before rendering again. This is disabled by default.

See also: setSwapInterval

◆ setImageCacheSize()

void juce::OpenGLContext::setImageCacheSize ( size_t cacheSizeBytes )

noexcept

Changes the amount of GPU memory that the internal cache for Images is allowed to use.

◆ setMultisamplingEnabled()

void juce::OpenGLContext::setMultisamplingEnabled ( bool )

noexcept

Enables multisampling on platforms where this is implemented.

If enabling this, you must call this method before attachTo().

◆ setNativeSharedContext()

void juce::OpenGLContext::setNativeSharedContext ( void * nativeContextToShareWith )

noexcept

Provides a context with which you'd like this context's resources to be shared.

The object passed-in here is a platform-dependent native context object, and must not be deleted while this context may still be using it! To turn off sharing, you can call this method with a null pointer. Note: This must be called BEFORE attaching your context to a target component!

◆ setOpenGLVersionRequired()

void juce::OpenGLContext::setOpenGLVersionRequired ( OpenGLVersion )

noexcept

Sets a preference for the version of GL that this context should use, if possible.

Some platforms may ignore this value.

◆ setPixelFormat()

void juce::OpenGLContext::setPixelFormat ( const OpenGLPixelFormat & preferredPixelFormat )

noexcept

Sets the pixel format which you'd like to use for the target GL surface.

Note: This must be called BEFORE attaching your context to a target component!

◆ setRenderer()

void juce::OpenGLContext::setRenderer ( OpenGLRenderer * )

noexcept

Gives the context an OpenGLRenderer to use to do the drawing.

The object that you give it will not be owned by the context, so it's the caller's responsibility to manage its lifetime and make sure that it doesn't get deleted while the context may be using it. To stop the context using a renderer, just call this method with a null pointer. Note: This must be called BEFORE attaching your context to a target component!

◆ setSwapInterval()

bool juce::OpenGLContext::setSwapInterval ( int numFramesPerSwap )

Sets whether the context checks the vertical sync before swapping.

The value is the number of frames to allow between buffer-swapping. This is fairly system-dependent, but 0 turns off syncing, 1 makes it swap on frame-boundaries, and greater numbers indicate that it should swap less often.

By default, this will be set to 1.

Returns true if it sets the value successfully - some platforms won't support this setting.

See also: setContinuousRepainting

◆ setTextureMagnificationFilter()

void juce::OpenGLContext::setTextureMagnificationFilter ( TextureMagnificationFilter magFilterMode )

noexcept

Sets the texture magnification filter.

By default the texture magnification filter is linear. However, for faster rendering you may want to use the 'nearest' magnification filter. This option will not affect any textures created before this function was called.

◆ swapBuffers()

void juce::OpenGLContext::swapBuffers ( )

Swaps the buffers (if the context can do this).

There's normally no need to call this directly - the buffers will be swapped automatically after your OpenGLRenderer::renderOpenGL() method has been called.

◆ triggerRepaint()

void juce::OpenGLContext::triggerRepaint ( )

Asynchronously causes a repaint to be made.

Referenced by juce::OpenGLContext::NativeContext::dispatchDraw().

Friends And Related Function Documentation

◆ OpenGLTexture

friend class OpenGLTexture

friend

Member Data Documentation

◆ attachment

std::unique_ptr<Attachment> juce::OpenGLContext::attachment

private

◆ contextToShareWith

void* juce::OpenGLContext::contextToShareWith = nullptr

private

◆ continuousRepaint

std::atomic<bool> juce::OpenGLContext::continuousRepaint { false }

private

◆ currentRenderScale

double juce::OpenGLContext::currentRenderScale = 1.0

private

◆ extensions

OpenGLExtensionFunctions juce::OpenGLContext::extensions

This structure holds a set of dynamically loaded GL functions for use on this context.

◆ imageCacheMaxSize

size_t juce::OpenGLContext::imageCacheMaxSize = 8 * 1024 * 1024

private

◆ nativeContext

NativeContext* juce::OpenGLContext::nativeContext = nullptr

private

◆ openGLPixelFormat

OpenGLPixelFormat juce::OpenGLContext::openGLPixelFormat

private

◆ overrideCanAttach

bool juce::OpenGLContext::overrideCanAttach = false

private

◆ renderComponents

bool juce::OpenGLContext::renderComponents = true

private

◆ renderer

OpenGLRenderer* juce::OpenGLContext::renderer = nullptr

private

◆ texMagFilter

TextureMagnificationFilter juce::OpenGLContext::texMagFilter = linear

private

◆ useMultisampling

bool juce::OpenGLContext::useMultisampling = false

private

◆ versionRequired

OpenGLVersion juce::OpenGLContext::versionRequired = defaultGLVersion

private

The documentation for this class was generated from the following file:

juce_OpenGLContext.h

Classes

Public Types

Public Member Functions

Static Public Member Functions

Public Attributes

Private Member Functions

Private Attributes

Friends

Detailed Description

Member Enumeration Documentation

◆ OpenGLVersion

◆ TextureMagnificationFilter

Constructor & Destructor Documentation

◆ OpenGLContext()

◆ ~OpenGLContext()

Member Function Documentation

◆ areShadersAvailable()

◆ attachTo()

◆ copyTexture()

◆ deactivateCurrentContext()

◆ detach()

◆ execute()

◆ executeOnGLThread()

◆ getAssociatedObject()

◆ getCachedImage()

◆ getContextAttachedTo()

◆ getCurrentContext()

◆ getFrameBufferID()

◆ getImageCacheSize()

◆ getRawContext()

◆ getRenderingScale()

◆ getSwapInterval()

◆ getTargetComponent()

◆ isActive()

◆ isAttached()

◆ isTextureNpotSupported()

◆ makeActive()

◆ setAssociatedObject()

◆ setComponentPaintingEnabled()

◆ setContinuousRepainting()

◆ setImageCacheSize()

◆ setMultisamplingEnabled()

◆ setNativeSharedContext()

◆ setOpenGLVersionRequired()

◆ setPixelFormat()

◆ setRenderer()

◆ setSwapInterval()

◆ setTextureMagnificationFilter()

◆ swapBuffers()

◆ triggerRepaint()

Friends And Related Function Documentation

◆ OpenGLTexture

Member Data Documentation

◆ attachment

◆ contextToShareWith

◆ continuousRepaint

◆ currentRenderScale

◆ extensions

◆ imageCacheMaxSize

◆ nativeContext

◆ openGLPixelFormat

◆ overrideCanAttach

◆ renderComponents

◆ renderer

◆ texMagFilter

◆ useMultisampling

◆ versionRequired
