Basic interface for all solvers. More...
#include <opencv2/core/optim.hpp>
Classes | |
class | Function |
Represents function being optimized. More... | |
Public Member Functions | |
virtual void | clear () |
Clears the algorithm state. More... | |
virtual bool | empty () const |
Returns true if the Algorithm is empty (e.g. More... | |
virtual String | getDefaultName () const |
Returns the algorithm string identifier. More... | |
virtual Ptr< Function > | getFunction () const =0 |
Getter for the optimized function. More... | |
virtual TermCriteria | getTermCriteria () const =0 |
Getter for the previously set terminal criteria for this algorithm. More... | |
virtual double | minimize (InputOutputArray x)=0 |
actually runs the algorithm and performs the minimization. More... | |
virtual void | read (const FileNode &fn) |
Reads algorithm parameters from a file storage. More... | |
virtual void | save (const String &filename) const |
Saves the algorithm to a file. More... | |
virtual void | setFunction (const Ptr< Function > &f)=0 |
Setter for the optimized function. More... | |
virtual void | setTermCriteria (const TermCriteria &termcrit)=0 |
Set terminal criteria for solver. More... | |
virtual void | write (FileStorage &fs) const |
Stores algorithm parameters in a file storage. More... | |
void | write (const Ptr< FileStorage > &fs, const String &name=String()) const |
simplified API for language bindings This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts. More... | |
Static Public Member Functions | |
template<typename _Tp > | |
static Ptr< _Tp > | load (const String &filename, const String &objname=String()) |
Loads algorithm from the file. More... | |
template<typename _Tp > | |
static Ptr< _Tp > | loadFromString (const String &strModel, const String &objname=String()) |
Loads algorithm from a String. More... | |
template<typename _Tp > | |
static Ptr< _Tp > | read (const FileNode &fn) |
Reads algorithm from the file node. More... | |
Protected Member Functions | |
void | writeFormat (FileStorage &fs) const |
Basic interface for all solvers.
|
inlinevirtualinherited |
Clears the algorithm state.
Reimplemented in cv::FlannBasedMatcher, and cv::DescriptorMatcher.
|
inlinevirtualinherited |
Returns true if the Algorithm is empty (e.g.
in the very beginning or after unsuccessful read
Reimplemented in cv::DescriptorMatcher, cv::ml::StatModel, cv::Feature2D, and cv::BaseCascadeClassifier.
|
virtualinherited |
Returns the algorithm string identifier.
This string is used as top level xml/yml node tag when the object is saved to a file or string.
Reimplemented in cv::AKAZE, cv::KAZE, cv::SimpleBlobDetector, cv::GFTTDetector, cv::AgastFeatureDetector, cv::FastFeatureDetector, cv::MSER, cv::ORB, cv::BRISK, and cv::Feature2D.
Getter for the optimized function.
The optimized function is represented by Function interface, which requires derivatives to implement the calc(double*) and getDim() methods to evaluate the function.
|
pure virtual |
Getter for the previously set terminal criteria for this algorithm.
|
inlinestaticinherited |
Loads algorithm from the file.
filename | Name of the file to read. |
objname | The optional name of the node to read (if empty, the first top-level node will be used) |
This is static template method of Algorithm. It's usage is following (in the case of SVM):
In order to make this method work, the derived class must overwrite Algorithm::read(const FileNode& fn).
References CV_Assert, cv::FileNode::empty(), cv::FileStorage::getFirstTopLevelNode(), cv::FileStorage::isOpened(), and cv::FileStorage::READ.
|
inlinestaticinherited |
Loads algorithm from a String.
strModel | The string variable containing the model you want to load. |
objname | The optional name of the node to read (if empty, the first top-level node will be used) |
This is static template method of Algorithm. It's usage is following (in the case of SVM):
References CV_WRAP, cv::FileNode::empty(), cv::FileStorage::getFirstTopLevelNode(), cv::FileStorage::MEMORY, and cv::FileStorage::READ.
|
pure virtual |
actually runs the algorithm and performs the minimization.
The sole input parameter determines the centroid of the starting simplex (roughly, it tells where to start), all the others (terminal criteria, initial step, function to be minimized) are supposed to be set via the setters before the call to this method or the default values (not always sensible) will be used.
x | The initial point, that will become a centroid of an initial simplex. After the algorithm will terminate, it will be set to the point where the algorithm stops, the point of possible minimum. |
|
inlinevirtualinherited |
Reads algorithm parameters from a file storage.
Reimplemented in cv::FlannBasedMatcher, cv::DescriptorMatcher, and cv::Feature2D.
|
inlinestaticinherited |
Reads algorithm from the file node.
This is static template method of Algorithm. It's usage is following (in the case of SVM):
In order to make this method work, the derived class must overwrite Algorithm::read(const FileNode& fn) and also have static create() method without parameters (or with all the optional parameters)
|
virtualinherited |
Saves the algorithm to a file.
In order to make this method work, the derived class must implement Algorithm::write(FileStorage& fs).
Setter for the optimized function.
It should be called at least once before the call to* minimize(), as default value is not usable.
f | The new function to optimize. |
|
pure virtual |
Set terminal criteria for solver.
This method is not necessary to be called before the first call to minimize(), as the default value is sensible.
Algorithm stops when the number of function evaluations done exceeds termcrit.maxCount, when the function values at the vertices of simplex are within termcrit.epsilon range or simplex becomes so small that it can enclosed in a box with termcrit.epsilon sides, whatever comes first.
termcrit | Terminal criteria to be used, represented as cv::TermCriteria structure. |
|
inlinevirtualinherited |
Stores algorithm parameters in a file storage.
Reimplemented in cv::FlannBasedMatcher, cv::DescriptorMatcher, and cv::Feature2D.
References CV_WRAP.
Referenced by cv::Feature2D::write(), and cv::DescriptorMatcher::write().
|
inherited |
simplified API for language bindings This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts.
|
protectedinherited |
