Collaboration diagram for Graph API: Math operations:

Functions
GMat	cv::gapi::add (const GMat &src1, const GMat &src2, int ddepth=-1)
	Calculates the per-element sum of two matrices. More...

GMat	cv::gapi::addC (const GMat &src1, const GScalar &c, int ddepth=-1)
	Calculates the per-element sum of matrix and given scalar. More...

GMat	cv::gapi::addC (const GScalar &c, const GMat &src1, int ddepth=-1)

std::tuple< GMat, GMat >	cv::gapi::cartToPolar (const GMat &x, const GMat &y, bool angleInDegrees=false)
	Calculates the magnitude and angle of 2D vectors. More...

GMat	cv::gapi::div (const GMat &src1, const GMat &src2, double scale, int ddepth=-1)
	Performs per-element division of two matrices. More...

GMat	cv::gapi::divC (const GMat &src, const GScalar &divisor, double scale, int ddepth=-1)
	Divides matrix by scalar. More...

GMat	cv::gapi::divRC (const GScalar &divident, const GMat &src, double scale, int ddepth=-1)
	Divides scalar by matrix. More...

GMat	cv::gapi::mask (const GMat &src, const GMat &mask)
	Applies a mask to a matrix. More...

GScalar	cv::gapi::mean (const GMat &src)
	Calculates an average (mean) of matrix elements. More...

GMat	cv::gapi::mul (const GMat &src1, const GMat &src2, double scale=1.0, int ddepth=-1)
	Calculates the per-element scaled product of two matrices. More...

GMat	cv::gapi::mulC (const GMat &src, double multiplier, int ddepth=-1)
	Multiplies matrix by scalar. More...

GMat	cv::gapi::mulC (const GMat &src, const GScalar &multiplier, int ddepth=-1)

GMat	cv::gapi::mulC (const GScalar &multiplier, const GMat &src, int ddepth=-1)

GMat	cv::gapi::phase (const GMat &x, const GMat &y, bool angleInDegrees=false)
	Calculates the rotation angle of 2D vectors. More...

std::tuple< GMat, GMat >	cv::gapi::polarToCart (const GMat &magnitude, const GMat &angle, bool angleInDegrees=false)
	Calculates x and y coordinates of 2D vectors from their magnitude and angle. More...

GMat	cv::gapi::sqrt (const GMat &src)
	Calculates a square root of array elements. More...

GMat	cv::gapi::sub (const GMat &src1, const GMat &src2, int ddepth=-1)
	Calculates the per-element difference between two matrices. More...

GMat	cv::gapi::subC (const GMat &src, const GScalar &c, int ddepth=-1)
	Calculates the per-element difference between matrix and given scalar. More...

GMat	cv::gapi::subRC (const GScalar &c, const GMat &src, int ddepth=-1)
	Calculates the per-element difference between given scalar and the matrix. More...

Detailed Description

Function Documentation

◆ add()

GMat cv::gapi::add	(	const GMat &	src1,
		const GMat &	src2,
		int	ddepth = `-1`
	)

#include <opencv2/gapi/core.hpp>

Calculates the per-element sum of two matrices.

The function add calculates sum of two matrices of the same size and the same number of channels:

\[\texttt{dst}(I) = \texttt{saturate} ( \texttt{src1}(I) + \texttt{src2}(I)) \quad \texttt{if mask}(I) \ne0\]

The function can be replaced with matrix expressions:

\[\texttt{dst} = \texttt{src1} + \texttt{src2}\]

The input matrices and the output matrix can all have the same or different depths. For example, you can add a 16-bit unsigned matrix to a 8-bit signed matrix and store the sum as a 32-bit floating-point matrix. Depth of the output matrix is determined by the ddepth parameter. If src1.depth() == src2.depth(), ddepth can be set to the default -1. In this case, the output matrix will have the same depth as the input matrices.

Supported matrix data types are CV_8UC1, CV_8UC3, CV_16UC1, CV_16SC1, CV_32FC1.

Note: Function textual ID is "org.opencv.core.math.add"

Parameters

src1	first input matrix.
src2	second input matrix.
ddepth	optional depth of the output matrix.

See also: sub, addWeighted

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

◆ addC() [1/2]

GMat cv::gapi::addC	(	const GMat &	src1,
		const GScalar &	c,
		int	ddepth = `-1`
	)

#include <opencv2/gapi/core.hpp>

Calculates the per-element sum of matrix and given scalar.

The function addC adds a given scalar value to each element of given matrix. The function can be replaced with matrix expressions:

\[\texttt{dst} = \texttt{src1} + \texttt{c}\]

Depth of the output matrix is determined by the ddepth parameter. If ddepth is set to default -1, the depth of output matrix will be the same as the depth of input matrix. The matrices can be single or multi channel. Output matrix must have the same size and number of channels as the input matrix.

Supported matrix data types are CV_8UC1, CV_8UC3, CV_16UC1, CV_16SC1, CV_32FC1.

Note: Function textual ID is "org.opencv.core.math.addC"

Parameters

src1	first input matrix.
c	scalar value to be added.
ddepth	optional depth of the output matrix.

See also: sub, addWeighted

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

◆ addC() [2/2]

GMat cv::gapi::addC	(	const GScalar &	c,
		const GMat &	src1,
		int	ddepth = `-1`
	)

#include <opencv2/gapi/core.hpp>

This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts.

◆ cartToPolar()

std::tuple<GMat, GMat> cv::gapi::cartToPolar	(	const GMat &	x,
		const GMat &	y,
		bool	angleInDegrees = `false`
	)

#include <opencv2/gapi/core.hpp>

Calculates the magnitude and angle of 2D vectors.

The function cartToPolar calculates either the magnitude, angle, or both for every 2D vector (x(I),y(I)):

\[\begin{array}{l} \texttt{magnitude} (I)= \sqrt{\texttt{x}(I)^2+\texttt{y}(I)^2} , \\ \texttt{angle} (I)= \texttt{atan2} ( \texttt{y} (I), \texttt{x} (I))[ \cdot180 / \pi ] \end{array}\]

The angles are calculated with accuracy about 0.3 degrees. For the point (0,0), the angle is set to 0.

First output is a matrix of magnitudes of the same size and depth as input x. Second output is a matrix of angles that has the same size and depth as x; the angles are measured in radians (from 0 to 2*Pi) or in degrees (0 to 360 degrees).

Note: Function textual ID is "org.opencv.core.math.cartToPolar"

Parameters

x	matrix of CV_32FC1 x-coordinates.
y	array of CV_32FC1 y-coordinates.
angleInDegrees	a flag, indicating whether the angles are measured in radians (which is by default), or in degrees.

See also: polarToCart

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

◆ div()

GMat cv::gapi::div	(	const GMat &	src1,
		const GMat &	src2,
		double	scale,
		int	ddepth = `-1`
	)

#include <opencv2/gapi/core.hpp>

Performs per-element division of two matrices.

The function divides one matrix by another:

\[\texttt{dst(I) = saturate(src1(I)*scale/src2(I))}\]

When src2(I) is zero, dst(I) will also be zero. Different channels of multi-channel matrices are processed independently. The matrices can be single or multi channel. Output matrix must have the same size and depth as src.

Supported matrix data types are CV_8UC1, CV_8UC3, CV_16UC1, CV_16SC1, CV_32FC1.

Note: Function textual ID is "org.opencv.core.math.div"

Parameters

src1	first input matrix.
src2	second input matrix of the same size and depth as src1.
scale	scalar factor.
ddepth	optional depth of the output matrix; you can only pass -1 when src1.depth() == src2.depth().

See also: mul, add, sub

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

◆ divC()

GMat cv::gapi::divC	(	const GMat &	src,
		const GScalar &	divisor,
		double	scale,
		int	ddepth = `-1`
	)

#include <opencv2/gapi/core.hpp>

Divides matrix by scalar.

The function divC divides each element of matrix src by given scalar value:

\[\texttt{dst(I) = saturate(src(I)*scale/divisor)}\]

When divisor is zero, dst(I) will also be zero. Different channels of multi-channel matrices are processed independently. The matrices can be single or multi channel. Output matrix must have the same size and depth as src.

Supported matrix data types are CV_8UC1, CV_8UC3, CV_16UC1, CV_16SC1, CV_32FC1.

Note: Function textual ID is "org.opencv.core.math.divC"

Parameters

src	input matrix.
divisor	number to be divided by.
ddepth	optional depth of the output matrix. If -1, the depth of output matrix will be the same as input matrix depth.
scale	scale factor.

See also: add, sub, div, addWeighted

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

◆ divRC()

GMat cv::gapi::divRC	(	const GScalar &	divident,
		const GMat &	src,
		double	scale,
		int	ddepth = `-1`
	)

#include <opencv2/gapi/core.hpp>

Divides scalar by matrix.

The function divRC divides given scalar by each element of matrix src and keep the division result in new matrix of the same size and type as src:

\[\texttt{dst(I) = saturate(divident*scale/src(I))}\]

When src(I) is zero, dst(I) will also be zero. Different channels of multi-channel matrices are processed independently. The matrices can be single or multi channel. Output matrix must have the same size and depth as src.

Supported matrix data types are CV_8UC1, CV_8UC3, CV_16UC1, CV_16SC1, CV_32FC1.

Note: Function textual ID is "org.opencv.core.math.divRC"

Parameters

src	input matrix.
divident	number to be divided.
ddepth	optional depth of the output matrix. If -1, the depth of output matrix will be the same as input matrix depth.
scale	scale factor

See also: add, sub, div, addWeighted

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

◆ mask()

GMat cv::gapi::mask	(	const GMat &	src,
		const GMat &	mask
	)

#include <opencv2/gapi/core.hpp>

Applies a mask to a matrix.

The function mask set value from given matrix if the corresponding pixel value in mask matrix set to true, and set the matrix value to 0 overwise.

Supported src matrix data types are CV_8UC1, CV_16SC1, CV_16UC1. Supported mask data type is CV_8UC1.

Note: Function textual ID is "org.opencv.core.math.mask"

Parameters

src	input matrix.
mask	input mask matrix.

Examples:: samples/cpp/camshiftdemo.cpp, samples/cpp/create_mask.cpp, samples/cpp/ffilldemo.cpp, samples/cpp/grabcut.cpp, samples/cpp/segment_objects.cpp, samples/cpp/stitching_detailed.cpp, samples/cpp/tutorial_code/Histograms_Matching/MatchTemplate_Demo.cpp, and samples/cpp/tutorial_code/photo/seamless_cloning/cloning_demo.cpp.

Referenced by cv::detail::BlocksGainCompensator::apply(), cv::detail::BlocksCompensator::BlocksCompensator(), cv::detail::ChannelsCompensator::ChannelsCompensator(), cv::gapi::core::G_TYPED_KERNEL(), cv::detail::GainCompensator::GainCompensator(), cv::detail::ImageFeatures::getKeypoints(), cv::KeyPointsFilter::KeyPointsFilter(), cv::morphologyDefaultBorderValue(), cv::detail::FeaturesMatcher::operator()(), cv::detail::MultiBandBlender::setNumBands(), cv::detail::FeatherBlender::setSharpness(), cv::v_absdiff(), cv::v_pack_b(), cv::v_signmask(), cv::LMSolver::Callback::~Callback(), and cv::detail::Timelapser::~Timelapser().

Here is the caller graph for this function:

◆ mean()

GScalar cv::gapi::mean ( const GMat & src )

#include <opencv2/gapi/core.hpp>

Calculates an average (mean) of matrix elements.

The function mean calculates the mean value M of matrix elements, independently for each channel, and return it.

Supported matrix data types are CV_8UC1, CV_8UC3, CV_16UC1, CV_16SC1, CV_32FC1.

Note: Function textual ID is "org.opencv.core.math.mean"

Parameters

src	input matrix.

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

◆ mul()

GMat cv::gapi::mul	(	const GMat &	src1,
		const GMat &	src2,
		double	scale = `1.0`,
		int	ddepth = `-1`
	)

#include <opencv2/gapi/core.hpp>

Calculates the per-element scaled product of two matrices.

The function mul calculates the per-element product of two matrices:

\[\texttt{dst} (I)= \texttt{saturate} ( \texttt{scale} \cdot \texttt{src1} (I) \cdot \texttt{src2} (I))\]

If src1.depth() == src2.depth(), ddepth can be set to the default -1. In this case, the output matrix will have the same depth as the input matrices. The matrices can be single or multi channel. Output matrix must have the same size as input matrices.

Supported matrix data types are CV_8UC1, CV_8UC3, CV_16UC1, CV_16SC1, CV_32FC1.

Note: Function textual ID is "org.opencv.core.math.mul"

Parameters

src1	first input matrix.
src2	second input matrix of the same size and the same depth as src1.
scale	optional scale factor.
ddepth	optional depth of the output matrix.

See also: add, sub, div, addWeighted

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

◆ mulC() [1/3]

GMat cv::gapi::mulC	(	const GMat &	src,
		double	multiplier,
		int	ddepth = `-1`
	)

#include <opencv2/gapi/core.hpp>

Multiplies matrix by scalar.

The function mulC multiplies each element of matrix src by given scalar value:

\[\texttt{dst} (I)= \texttt{saturate} ( \texttt{src1} (I) \cdot \texttt{multiplier} )\]

The matrices can be single or multi channel. Output matrix must have the same size as src.

Supported matrix data types are CV_8UC1, CV_8UC3, CV_16UC1, CV_16SC1, CV_32FC1.

Note: Function textual ID is "org.opencv.core.math.mulC"

Parameters

src	input matrix.
multiplier	factor to be multiplied.
ddepth	optional depth of the output matrix. If -1, the depth of output matrix will be the same as input matrix depth.

See also: add, sub, div, addWeighted

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

◆ mulC() [2/3]

GMat cv::gapi::mulC	(	const GMat &	src,
		const GScalar &	multiplier,
		int	ddepth = `-1`
	)

#include <opencv2/gapi/core.hpp>

This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts.

◆ mulC() [3/3]

GMat cv::gapi::mulC	(	const GScalar &	multiplier,
		const GMat &	src,
		int	ddepth = `-1`
	)

#include <opencv2/gapi/core.hpp>

This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts.

◆ phase()

GMat cv::gapi::phase	(	const GMat &	x,
		const GMat &	y,
		bool	angleInDegrees = `false`
	)

#include <opencv2/gapi/core.hpp>

Calculates the rotation angle of 2D vectors.

The function cv::phase calculates the rotation angle of each 2D vector that is formed from the corresponding elements of x and y :

\[\texttt{angle} (I) = \texttt{atan2} ( \texttt{y} (I), \texttt{x} (I))\]

The angle estimation accuracy is about 0.3 degrees. When x(I)=y(I)=0 , the corresponding angle(I) is set to 0.

Parameters

x	input floating-point array of x-coordinates of 2D vectors.
y	input array of y-coordinates of 2D vectors; it must have the same size and the same type as x.
angleInDegrees	when true, the function calculates the angle in degrees, otherwise, they are measured in radians.

Returns: array of vector angles; it has the same size and same type as x.

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

◆ polarToCart()

std::tuple<GMat, GMat> cv::gapi::polarToCart	(	const GMat &	magnitude,
		const GMat &	angle,
		bool	angleInDegrees = `false`
	)

#include <opencv2/gapi/core.hpp>

Calculates x and y coordinates of 2D vectors from their magnitude and angle.

The function polarToCart calculates the Cartesian coordinates of each 2D vector represented by the corresponding elements of magnitude and angle:

\[\begin{array}{l} \texttt{x} (I) = \texttt{magnitude} (I) \cos ( \texttt{angle} (I)) \\ \texttt{y} (I) = \texttt{magnitude} (I) \sin ( \texttt{angle} (I)) \\ \end{array}\]

The relative accuracy of the estimated coordinates is about 1e-6.

First output is a matrix of x-coordinates of 2D vectors. Second output is a matrix of y-coordinates of 2D vectors. Both output must have the same size and depth as input matrices.

Note: Function textual ID is "org.opencv.core.math.polarToCart"

Parameters

magnitude	input floating-point CV_32FC1 matrix (1xN) of magnitudes of 2D vectors;
angle	input floating-point CV_32FC1 matrix (1xN) of angles of 2D vectors.
angleInDegrees	when true, the input angles are measured in degrees, otherwise, they are measured in radians.

See also: cartToPolar, exp, log, pow, sqrt

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

◆ sqrt()

GMat cv::gapi::sqrt ( const GMat & src )

#include <opencv2/gapi/core.hpp>

Calculates a square root of array elements.

The function cv::gapi::sqrt calculates a square root of each input array element. In case of multi-channel arrays, each channel is processed independently. The accuracy is approximately the same as of the built-in std::sqrt .

Parameters

src	input floating-point array.

Returns: output array of the same size and type as src.

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

◆ sub()

GMat cv::gapi::sub	(	const GMat &	src1,
		const GMat &	src2,
		int	ddepth = `-1`
	)

#include <opencv2/gapi/core.hpp>

Calculates the per-element difference between two matrices.

The function sub calculates difference between two matrices, when both matrices have the same size and the same number of channels:

\[\texttt{dst}(I) = \texttt{src1}(I) - \texttt{src2}(I)\]

The function can be replaced with matrix expressions:

\[\texttt{dst} = \texttt{src1} - \texttt{src2}\]

The input matrices and the output matrix can all have the same or different depths. For example, you can subtract two 8-bit unsigned matrices store the result as a 16-bit signed matrix. Depth of the output matrix is determined by the ddepth parameter. If src1.depth() == src2.depth(), ddepth can be set to the default -1. In this case, the output matrix will have the same depth as the input matrices. The matrices can be single or multi channel.

Supported matrix data types are CV_8UC1, CV_8UC3, CV_16UC1, CV_16SC1, CV_32FC1.

Note: Function textual ID is "org.opencv.core.math.sub"

Parameters

src1	first input matrix.
src2	second input matrix.
ddepth	optional depth of the output matrix.

See also: add, addC

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

◆ subC()

GMat cv::gapi::subC	(	const GMat &	src,
		const GScalar &	c,
		int	ddepth = `-1`
	)

#include <opencv2/gapi/core.hpp>

Calculates the per-element difference between matrix and given scalar.

The function can be replaced with matrix expressions:

\[\texttt{dst} = \texttt{src} - \texttt{c}\]

Depth of the output matrix is determined by the ddepth parameter. If ddepth is set to default -1, the depth of output matrix will be the same as the depth of input matrix. The matrices can be single or multi channel. Output matrix must have the same size as src.

Supported matrix data types are CV_8UC1, CV_8UC3, CV_16UC1, CV_16SC1, CV_32FC1.

Note: Function textual ID is "org.opencv.core.math.subC"

Parameters

src	first input matrix.
c	scalar value to subtracted.
ddepth	optional depth of the output matrix.

See also: add, addC, subRC

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

◆ subRC()

GMat cv::gapi::subRC	(	const GScalar &	c,
		const GMat &	src,
		int	ddepth = `-1`
	)

#include <opencv2/gapi/core.hpp>

Calculates the per-element difference between given scalar and the matrix.

The function can be replaced with matrix expressions:

\[\texttt{dst} = \texttt{val} - \texttt{src}\]

Depth of the output matrix is determined by the ddepth parameter. If ddepth is set to default -1, the depth of output matrix will be the same as the depth of input matrix. The matrices can be single or multi channel. Output matrix must have the same size as src.

Supported matrix data types are CV_8UC1, CV_8UC3, CV_16UC1, CV_16SC1, CV_32FC1.

Note: Function textual ID is "org.opencv.core.math.subRC"

Parameters

c	scalar value to subtract from.
src	input matrix to be subtracted.
ddepth	optional depth of the output matrix.

See also: add, addC, subC

Referenced by cv::gapi::core::G_TYPED_KERNEL().

Here is the caller graph for this function:

Functions

Detailed Description

Function Documentation

◆ add()

◆ addC() [1/2]

◆ addC() [2/2]

◆ cartToPolar()

◆ div()

◆ divC()

◆ divRC()

◆ mask()

◆ mean()

◆ mul()

◆ mulC() [1/3]

◆ mulC() [2/3]

◆ mulC() [3/3]

◆ phase()

◆ polarToCart()

◆ sqrt()

◆ sub()

◆ subC()

◆ subRC()
