Features matcher similar to cv::detail::BestOf2NearestMatcher which finds two best matches for each feature and leaves the best one only if the ratio between descriptor distances is greater than the threshold match_conf.
More...
#include <opencv2/stitching/detail/matchers.hpp>
Features matcher similar to cv::detail::BestOf2NearestMatcher which finds two best matches for each feature and leaves the best one only if the ratio between descriptor distances is greater than the threshold match_conf.
Unlike cv::detail::BestOf2NearestMatcher this matcher uses affine transformation (affine trasformation estimate will be placed in matches_info).
- See also
- cv::detail::FeaturesMatcher cv::detail::BestOf2NearestMatcher
◆ AffineBestOf2NearestMatcher()
cv::detail::AffineBestOf2NearestMatcher::AffineBestOf2NearestMatcher |
( |
bool |
full_affine = false , |
|
|
bool |
try_use_gpu = false , |
|
|
float |
match_conf = 0.3f , |
|
|
int |
num_matches_thresh1 = 6 |
|
) |
| |
|
inline |
Constructs a "best of 2 nearest" matcher that expects affine trasformation between images.
- Parameters
-
full_affine | whether to use full affine transformation with 6 degress of freedom or reduced transformation with 4 degrees of freedom using only rotation, translation and uniform scaling |
try_use_gpu | Should try to use GPU or not |
match_conf | Match distances ration threshold |
num_matches_thresh1 | Minimum number of matches required for the 2D affine transform estimation used in the inliers classification step |
- See also
- cv::estimateAffine2D cv::estimateAffinePartial2D
References CV_OVERRIDE.
◆ collectGarbage()
void cv::detail::BestOf2NearestMatcher::collectGarbage |
( |
| ) |
|
|
virtualinherited |
◆ create()
static Ptr<BestOf2NearestMatcher> cv::detail::BestOf2NearestMatcher::create |
( |
bool |
try_use_gpu = false , |
|
|
float |
match_conf = 0.3f , |
|
|
int |
num_matches_thresh1 = 6 , |
|
|
int |
num_matches_thresh2 = 6 |
|
) |
| |
|
staticinherited |
◆ isThreadSafe()
bool cv::detail::FeaturesMatcher::isThreadSafe |
( |
| ) |
const |
|
inlineinherited |
- Returns
- True, if it's possible to use the same matcher instance in parallel, false otherwise
◆ match()
This method must implement matching logic in order to make the wrappers detail::FeaturesMatcher::operator()_ work.
- Parameters
-
features1 | first image features |
features2 | second image features |
matches_info | found matches |
Reimplemented from cv::detail::BestOf2NearestMatcher.
◆ operator()() [1/2]
This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts.
- Parameters
-
features1 | First image features |
features2 | Second image features |
matches_info | Found matches |
References CV_OUT, CV_WRAP_AS, and cv::gapi::mask().
◆ operator()() [2/2]
Performs images matching.
- Parameters
-
features | Features of the source images |
pairwise_matches | Found pairwise matches |
mask | Mask indicating which image pairs must be matched |
The function is parallelized with the TBB library.
- See also
- detail::MatchesInfo
◆ full_affine_
bool cv::detail::AffineBestOf2NearestMatcher::full_affine_ |
|
protected |
◆ impl_
◆ is_thread_safe_
bool cv::detail::FeaturesMatcher::is_thread_safe_ |
|
protectedinherited |
◆ num_matches_thresh1_
int cv::detail::BestOf2NearestMatcher::num_matches_thresh1_ |
|
protectedinherited |
◆ num_matches_thresh2_
int cv::detail::BestOf2NearestMatcher::num_matches_thresh2_ |
|
protectedinherited |
The documentation for this class was generated from the following file:
- opencv2/stitching/detail/matchers.hpp
