HPS::EventDispatcher Class Reference

The EventDispatcher class is used for injecting any events and dealing with event handlers which handle those events. More...

#include <hps.h>

Inheritance diagram for HPS::EventDispatcher:

Collaboration diagram for HPS::EventDispatcher:

Public Member Functions
	EventDispatcher ()
	The default constructor creates an uninitialized EventDispatcher object which cannot be subscribed to. More...
	EventDispatcher (EventDispatcher const &in_that)
	The copy constructor creates an EventDispatcher object that points to the same underlying impl as the source EventDispatcher. More...
	EventDispatcher (EventDispatcher &&in_that)
	The move constructor creates a EventDispatcher by transferring the underlying impl of the rvalue reference to this EventDispatcher thereby avoiding a copy and allocation. More...
EventDispatcher &	operator= (EventDispatcher &&in_that)
	The move assignment operator transfers the underlying impl of the rvalue reference to this EventDispatcher thereby avoiding a copy. More...
virtual	~EventDispatcher ()
HPS::Type	ObjectType () const
EventDispatcher &	operator= (EventDispatcher const &in_that)
	Associate this EventDispatcher with the same underlying impl as the source EventDispatcher. More...
bool	Equals (EventDispatcher const &in_that) const
	Check if the source EventDispatcher is equivalent to this object. More...
bool	operator== (EventDispatcher const &in_that) const
	Check if the source EventDispatcher is equivalent to this object. More...
bool	operator!= (EventDispatcher const &in_that) const
	Check if the source EventDispatcher is not equivalent to this object. More...
bool	Subscribe (EventHandler const &in_handler, intptr_t in_type) const
	Add the specified event handler to the list of subscribers for events of the specified type on this EventDispatcher. More...
bool	UnSubscribe (EventHandler const &in_handler, intptr_t in_type) const
	Remove the specified event handler from the list of subscribers for events of the specified type on this EventDispatcher. More...
bool	UnSubscribe (EventHandler const &in_handler) const
	Remove the specified event handler from the list of subscribers for events of the specified type on this EventDispatcher. More...
bool	UnSubscribe (intptr_t in_type) const
	Remove the specified event handler from the list of subscribers for events of the specified type on this EventDispatcher. More...
bool	InjectEvent (Event const &in_event) const
	Inject the specified event and propagate it to all subscribed handlers in the order of subscription. More...
EventNotifier	InjectEventWithNotifier (Event const &in_event) const
	Inject the specified event and propagate it to all subscribed handlers in the order of subscription and return an EventNotifier associated with the injected event. More...
void	Shutdown () const
	Shutdown this EventDispatcher asynchronously. More...
bool	IsShutdown () const
	Query whether the asynchronous shutdown has completed. More...
void	SetName (char const *in_name) const
	Sets the EventDispatcher's name. More...
void	ShowName (UTF8 &out_name) const
	Shows the EventDispatcher's name. More...
virtual HPS::Type	Type () const
	This function returns the true type of the underlying object. More...
virtual bool	Empty () const
	Indicates whether this object has any values set on it. More...
bool	HasType (HPS::Type in_mask) const
	This function indicates whether this Object has the given Type mask. More...
intptr_t	GetClassID () const
	Returns a unique identifier that is shared by all objects of the same class. More...
intptr_t	GetInstanceID () const
	Returns an identifier that can be used to identify which instance of a class an object is. More...

Static Public Member Functions
template<typename T >
static intptr_t	ClassID ()
	Unique identifier for this class. More...

Static Public Attributes
static const HPS::Type	staticType = HPS::Type::EventDispatcher

Private Member Functions
virtual void	Reset ()
	Not available here. More...

Detailed Description

The EventDispatcher class is used for injecting any events and dealing with event handlers which handle those events.

Constructor & Destructor Documentation

EventDispatcher() [1/3]

HPS::EventDispatcher::EventDispatcher

(

)

The default constructor creates an uninitialized EventDispatcher object which cannot be subscribed to.

See also

Database::CreateEventDispatcher()

EventDispatcher() [2/3]

HPS::EventDispatcher::EventDispatcher

(

EventDispatcher const &

in_that

)

The copy constructor creates an EventDispatcher object that points to the same underlying impl as the source EventDispatcher.

Parameters

in_that

The source EventHandler to point to.

EventDispatcher() [3/3]

HPS::EventDispatcher::EventDispatcher

(

EventDispatcher &&

in_that

)

The move constructor creates a EventDispatcher by transferring the underlying impl of the rvalue reference to this EventDispatcher thereby avoiding a copy and allocation.

Parameters

in_that

An rvalue reference to a EventDispatcher to take the impl from.

~EventDispatcher()

virtual HPS::EventDispatcher::~EventDispatcher ( )

virtual

Member Function Documentation

ClassID()

template<typename T >

static intptr_t HPS::Object::ClassID ( )

inlinestaticinherited

Unique identifier for this class.

Note: this method uses construction of static objects. If used in a constructor, it should be used in the body not the initializer list.

Empty()

virtual bool HPS::Object::Empty ( ) const

inlinevirtualinherited

Indicates whether this object has any values set on it.

Returns

true if no values are set on this object, false otherwise.

Reimplemented in HPS::STL::ImportResultsKit, HPS::STL::ImportOptionsKit, HPS::OBJ::ImportResultsKit, HPS::OBJ::ImportOptionsKit, HPS::Hardcopy::File::ExportOptionsKit, HPS::Stream::ExportOptionsKit, HPS::Stream::ImportResultsKit, HPS::Stream::ImportOptionsKit, HPS::PointCloud::ImportOptionsKit, HPS::PointCloud::ImportResultsKit, HPS::UpdateOptionsKit, HPS::HighlightSearchOptionsKit, HPS::HighlightOptionsKit, HPS::SelectionOptionsKit, HPS::SearchOptionsKit, HPS::CutGeometryGatheringOptionsKit, HPS::ShapeKit, HPS::ShaderKit, HPS::Shader::ImportOptionsKit, HPS::ImageKit, HPS::Image::ImportOptionsKit, HPS::Image::ExportOptionsKit, HPS::TextureOptionsKit, HPS::LinePatternKit, HPS::LinePatternParallelKit, HPS::LinePatternOptionsKit, HPS::GlyphKit, HPS::ApplicationWindowOptionsKit, HPS::OffScreenWindowOptionsKit, HPS::StandAloneWindowOptionsKit, HPS::GridKit, HPS::PolygonKit, HPS::MeshKit, HPS::ShellKit, HPS::ShellRelationResultsKit, HPS::ShellRelationOptionsKit, HPS::ShellOptimizationOptionsKit, HPS::TextKit, HPS::EllipticalArcKit, HPS::EllipseKit, HPS::TrimKit, HPS::NURBSSurfaceKit, HPS::NURBSCurveKit, HPS::SpotlightKit, HPS::InfiniteLineKit, HPS::CuttingSectionKit, HPS::CircularWedgeKit, HPS::CircularArcKit, HPS::CircleKit, HPS::SphereKit, HPS::CylinderKit, HPS::DistantLightKit, HPS::MarkerKit, HPS::LineKit, HPS::AttributeLockKit, HPS::FontInfoState, HPS::WindowInfoKit, HPS::DebuggingKit, HPS::SubwindowKit, HPS::ContourLineKit, HPS::VisualEffectsKit, HPS::TransformMaskKit, HPS::PostProcessEffectsKit, HPS::DrawingAttributeKit, HPS::HiddenLineAttributeKit, HPS::PerformanceKit, HPS::NURBSSurfaceAttributeKit, HPS::MaterialKit, HPS::MaterialMappingKit, HPS::MatrixKit, HPS::CurveAttributeKit, HPS::EdgeAttributeKit, HPS::LineAttributeKit, HPS::TextAttributeKit, HPS::CuttingSectionAttributeKit, HPS::CylinderAttributeKit, HPS::LightingAttributeKit, HPS::SphereAttributeKit, HPS::MarkerAttributeKit, HPS::CullingKit, HPS::ColorInterpolationKit, HPS::TransparencyKit, HPS::SelectabilityKit, HPS::CameraKit, HPS::VisibilityKit, HPS::BoundingKit, HPS::SegmentOptimizationOptionsKit, HPS::Publish::ExportOptionsKit, HPS::Publish::TextFieldKit, HPS::Publish::SignatureFieldKit, HPS::Publish::DropDownListKit, HPS::Exchange::TessellationOptionsKit, HPS::Publish::ListBoxKit, HPS::Exchange::ExportSTEPOptionsKit, HPS::Exchange::ExportParasolidOptionsKit, HPS::Publish::RadioButtonKit, HPS::Exchange::ExportIGESOptionsKit, HPS::Exchange::ExportXMLOptionsKit, HPS::Publish::CheckBoxKit, HPS::Exchange::ExportU3DOptionsKit, HPS::Exchange::ExportSTLOptionsKit, HPS::Publish::ButtonKit, HPS::Exchange::ExportPRCOptionsKit, HPS::Publish::LinkKit, HPS::Exchange::ExportJTOptionsKit, HPS::Publish::SlideTableKit, HPS::Exchange::ExportACISOptionsKit, HPS::Publish::TableKit, HPS::Exchange::Export3MFOptionsKit, HPS::Publish::ImageKit, HPS::Publish::TextKit, HPS::Exchange::ModelFileImportOptionsKit, HPS::Publish::ViewKit, HPS::Exchange::TranslationOptionsKit, HPS::Publish::ArtworkKit, HPS::Publish::AnnotationKit, HPS::ComponentPath, HPS::Exchange::ImportOptionsKit, HPS::Parasolid::ExportOptionsKit, HPS::Exchange::NURBSConversionOptionsKit, HPS::Parasolid::LineTessellationKit, HPS::Exchange::Configuration, HPS::Publish::PageKit, HPS::Parasolid::FacetTessellationKit, HPS::Publish::DocumentKit, HPS::Parasolid::ImportOptionsKit, HPS::DWG::ImportOptionsKit, HPS::OOC::ImportOptionsKit, HPS::Sketchup::ImportOptionsKit, and HPS::Sketchup::ImportResultsKit.

Equals()

bool HPS::EventDispatcher::Equals

(

EventDispatcher const &

in_that

)

const

Check if the source EventDispatcher is equivalent to this object.

Parameters

in_that

The source EventDispatcher to compare to this object.

Returns

true if the objects are equivalent, false otherwise.

GetClassID()

intptr_t HPS::Object::GetClassID ( ) const

inherited

Returns a unique identifier that is shared by all objects of the same class.

Returns

A unique value shared by all objects of the same class.

GetInstanceID()

intptr_t HPS::Object::GetInstanceID ( ) const

inherited

Returns an identifier that can be used to identify which instance of a class an object is.

Different keys and controls will return the same value if they are backed by the same database resource.

Returns

A value unique to an instance of an object and all objects that are backed by the same database resource.

HasType()

bool HPS::Object::HasType ( HPS::Type  in_mask ) const

inherited

This function indicates whether this Object has the given Type mask.

Parameters

in_mask

The Type mask to check against this Object.

Returns

true if this Object has the given Type mask, false otherwise.

InjectEvent()

bool HPS::EventDispatcher::InjectEvent

(

Event const &

in_event

)

const

Inject the specified event and propagate it to all subscribed handlers in the order of subscription.

Parameters

in_event

Event to inject and propagate.

Returns

true if the event injection was successful, false otherwise.

InjectEventWithNotifier()

EventNotifier HPS::EventDispatcher::InjectEventWithNotifier

(

Event const &

in_event

)

const

Inject the specified event and propagate it to all subscribed handlers in the order of subscription and return an EventNotifier associated with the injected event.

Parameters

in_event

Event to inject and propagate.

Returns

An event notifier associated with the injected event.

IsShutdown()

bool HPS::EventDispatcher::IsShutdown

(

)

const

Query whether the asynchronous shutdown has completed.

Returns

true if the event dispatcher has shutdown, false otherwise.

ObjectType()

HPS::Type HPS::EventDispatcher::ObjectType ( ) const

inlinevirtual

Reimplemented from HPS::Object.

Here is the call graph for this function:

operator!=()

bool HPS::EventDispatcher::operator!=

(

EventDispatcher const &

in_that

)

const

Check if the source EventDispatcher is not equivalent to this object.

Parameters

in_that

The source EventDispatcher to compare to this object.

Returns

true if the objects are not equivalent, false otherwise.

operator=() [1/2]

EventDispatcher& HPS::EventDispatcher::operator=

(

EventDispatcher &&

in_that

)

The move assignment operator transfers the underlying impl of the rvalue reference to this EventDispatcher thereby avoiding a copy.

Parameters

in_that

An rvalue reference to an EventDispatcher to take the impl from.

Returns

A reference to this EventDispatcher.

operator=() [2/2]

EventDispatcher& HPS::EventDispatcher::operator=

(

EventDispatcher const &

in_that

)

Associate this EventDispatcher with the same underlying impl as the source EventDispatcher.

Parameters

in_that

The source EventDispatcher for the assignment.

Returns

A reference to this EventDispatcher.

operator==()

bool HPS::EventDispatcher::operator==

(

EventDispatcher const &

in_that

)

const

Check if the source EventDispatcher is equivalent to this object.

Parameters

in_that

The source EventDispatcher to compare to this object.

Returns

true if the objects are equivalent, false otherwise.

Reset()

virtual void HPS::EventDispatcher::Reset ( )

inlineprivatevirtual

Not available here.

Reimplemented from HPS::Object.

SetName()

void HPS::EventDispatcher::SetName

(

char const *

in_name

)

const

Sets the EventDispatcher's name.

Parameters

in_name

Name to set.

ShowName()

void HPS::EventDispatcher::ShowName

(

UTF8 &

out_name

)

const

Shows the EventDispatcher's name.

Parameters

out_name

Current name of this EventDispatcher.

Shutdown()

void HPS::EventDispatcher::Shutdown

(

)

const

Shutdown this EventDispatcher asynchronously.

Any pending events injected into this EventDispatcher will be processed prior to shutdown, but no new events can be injected.

Subscribe()

bool HPS::EventDispatcher::Subscribe	(	EventHandler const &	in_handler,
		intptr_t	in_type
	)		const

Add the specified event handler to the list of subscribers for events of the specified type on this EventDispatcher.

Parameters

in_handler	Event handler to add to the subscriber list for events of the given type.
in_type	Type of event to add the handler for.

Returns

true if the subscription was successful, false otherwise.

Type()

virtual HPS::Type HPS::Object::Type ( ) const

virtualinherited

This function returns the true type of the underlying object.

This function is useful for finding the type of smart pointer objects that have been cast to more generic types.

Returns

The true type of the object in question.

Reimplemented in HPS::UpdateOptionsControl, HPS::HighlightControl, HPS::SelectionOptionsControl, HPS::OffScreenWindowOptionsControl, HPS::ApplicationWindowOptionsControl, HPS::StandAloneWindowOptionsControl, HPS::AttributeLockControl, HPS::WindowInfoControl, HPS::DebuggingControl, HPS::SubwindowControl, HPS::ContourLineControl, HPS::VisualEffectsControl, HPS::TransformMaskControl, HPS::PostProcessEffectsControl, HPS::DrawingAttributeControl, HPS::HiddenLineAttributeControl, HPS::PerformanceControl, HPS::NURBSSurfaceAttributeControl, HPS::ConditionControl, HPS::StyleControl, HPS::PortfolioControl, HPS::MaterialMappingControl, HPS::TextureMatrixControl, HPS::ModellingMatrixControl, HPS::CurveAttributeControl, HPS::EdgeAttributeControl, HPS::LineAttributeControl, HPS::TextAttributeControl, HPS::CuttingSectionAttributeControl, HPS::CylinderAttributeControl, HPS::LightingAttributeControl, HPS::SphereAttributeControl, HPS::MarkerAttributeControl, HPS::CullingControl, HPS::ColorInterpolationControl, HPS::TransparencyControl, HPS::SelectabilityControl, HPS::CameraControl, HPS::VisibilityControl, HPS::BoundingControl, HPS::Kit, and HPS::Control.

UnSubscribe() [1/3]

bool HPS::EventDispatcher::UnSubscribe	(	EventHandler const &	in_handler,
		intptr_t	in_type
	)		const

Remove the specified event handler from the list of subscribers for events of the specified type on this EventDispatcher.

Parameters

in_handler	Event handler to remove from the subscriber list for events of the given type.
in_type	Type of event to remove the handler for.

Returns

true if the unsubscription was successful, false otherwise.

UnSubscribe() [2/3]

bool HPS::EventDispatcher::UnSubscribe

(

EventHandler const &

in_handler

)

const

Remove the specified event handler from the list of subscribers for events of the specified type on this EventDispatcher.

Parameters

in_handler	Event handler to remove from the subscriber list for events of the given type.
in_type	Type of event to remove the handler for.

Returns

true if the unsubscription was successful, false otherwise.

UnSubscribe() [3/3]

bool HPS::EventDispatcher::UnSubscribe

(

intptr_t

in_type

)

const

Remove the specified event handler from the list of subscribers for events of the specified type on this EventDispatcher.

Parameters

in_type

Type of event to remove the handler for.

Returns

true if the unsubscription was successful, false otherwise.

Member Data Documentation

staticType

const HPS::Type HPS::EventDispatcher::staticType = HPS::Type::EventDispatcher

static

---

The documentation for this class was generated from the following file:

• hps.h
