HPS::ComponentTreeItem Class Reference

The ComponentTreeItem class is a smart pointer which corresponds to an item or node in a tree object in a GUI toolkit, e.g., a TreeViewItem in WPF or an HTREEITEM in MFC. More...

#include <sprk.h>

Inheritance diagram for HPS::ComponentTreeItem:

Collaboration diagram for HPS::ComponentTreeItem:

Public Member Functions
	ComponentTreeItem ()
	The default constructor creates an uninitialized ComponentTreeItem object. More...
	ComponentTreeItem (ComponentTreeItem const &in_that)
	The copy constructor creates a ComponentTreeItem object that shares the underlying smart-pointer of the source ComponentTreeItem. More...
	ComponentTreeItem (ComponentTreeItem &&in_that)
	The move constructor creates a ComponentTreeItem by transferring the underlying object of the rvalue reference to this ComponentTreeItem. More...
	ComponentTreeItem (ComponentTreePtr const &in_tree, CADModel const &in_cad_model)
	This constructor creates a ComponentTreeItem suitable for acting as a root in a ComponentTree. More...
	ComponentTreeItem (ComponentTreePtr const &in_tree, Component const &in_component, ComponentTree::ItemType in_type)
	This constructor creates a ComponentTreeItem which is not suitable for acting as a root in a ComponentTree, but is suitable to be a ComponentTreeItem under the root of the ComponentTree. More...
virtual	~ComponentTreeItem ()
HPS::Type	ObjectType () const
ComponentTreeItem &	operator= (ComponentTreeItem const &in_that)
	Share the underlying smart-pointer of the ComponentTreeItem source. More...
ComponentTreeItem &	operator= (ComponentTreeItem &&in_that)
	The move assignment operator transfers the underlying object of the rvalue reference to this ComponentTreeItem. More...
virtual void	Assign (ComponentTreeItem const &in_that)
	Share the underlying smart-pointer of the ComponentTreeItem source. More...
bool	Equals (ComponentTreeItem const &in_that) const
	Check if the source ComponentTreeItem points to the same underlying impl as this ComponentTreeItem. More...
bool	operator!= (ComponentTreeItem const &in_that) const
	Check if the source ComponentTreeItem points to a different impl than this ComponentTreeItem. More...
bool	operator== (ComponentTreeItem const &in_that) const
	Check if the source ComponentTreeItem points to the same underlying impl as this ComponentTreeItem. More...
ComponentTreePtr	GetTree () const
	Gets the ComponentTree associated with this ComponentTreeItem. More...
UTF8	GetTitle () const
	Gets the title for this ComponentTreeItem. More...
ComponentTree::ItemType	GetItemType () const
	Gets the item type for this ComponentTreeItem. More...
Component	GetComponent () const
	Gets the Component for this ComponentTreeItem. More...
bool	HasChildren () const
	Indicates whether this ComponentTreeItem has any children. More...
ComponentPath	GetPath () const
	Gets the ComponentPath corresponding to this ComponentTreeItem. More...
virtual ComponentTreeItemPtr	AddChild (Component const &in_component, ComponentTree::ItemType in_type)=0
	This function is used to create a new ComponentTreeItem to be the child of this ComponentTreeItem. More...
virtual void	Expand ()
	This function should be invoked when this ComponentTreeItem needs to expand. More...
virtual void	Collapse ()
	This function should be invoked when this ComponentTreeItem needs to collapse. More...
bool	IsHighlighted () const
	Indicates whether this ComponentTreeItem is currently highlighted with the options specified in the associated ComponentTree. More...
virtual void	OnHighlight (HighlightOptionsKit const &in_options)
	This function will be invoked when this ComponentTreeItem should be marked as highlighted. More...
virtual void	OnUnhighlight (HighlightOptionsKit const &in_options)
	This function will be invoked when this ComponentTreeItem should be marked as unhighlighted. More...
void	Highlight (size_t in_highlight_options_index=0)
	This function will cause this ComponentTreeItem to be highlighted with the nth option specified in the associated ComponentTree. More...
void	Highlight (HighlightOptionsKit const &in_highlight_options)
	This function will cause this ComponentTreeItem to be highlighted with the options specified. More...
void	Unhighlight (size_t in_highlight_options_index=0)
	This function will cause this ComponentTreeItem to be unhighlighted with the nth option specified in the associated ComponentTree. More...
void	Unhighlight (HighlightOptionsKit const &in_highlight_options)
	This function will cause this ComponentTreeItem to be unhighlighted with the options specified. More...
bool	IsHidden () const
	Indicates whether this ComponentTreeItem is currently hidden. More...
virtual void	OnHide ()
	This function will be invoked when this ComponentTreeItem should be marked as hidden. More...
virtual void	OnShow ()
	This function will be invoked when this ComponentTreeItem should be marked as visible. More...
void	Hide ()
	This function will cause this ComponentTreeItem to be hidden if it isn't already. More...
void	Show (Component::Visibility in_subtree_visibility=Component::Visibility::PreserveNone)
	This function will cause this ComponentTreeItem to be visible if it isn't already. More...
void	Isolate (Component::Visibility in_subtree_visibility=Component::Visibility::PreserveNone)
	This function will cause this ComponentTreeItem to be isolated, i.e., all other items will be hidden and this item will be shown. More...
bool	IsExpanded () const
	Indicates whether this ComponentTreeItem is currently expanded. More...
void	ReExpand ()
	Collapses this ComponentTreeItem and then re-expands the tree. More...
virtual HPS::Type	Type () const
	This function returns the true type of the underlying object. More...
virtual bool	Empty () const
	Indicates whether this object has any values set on it. More...
virtual void	Reset ()
	Resets this object to its initial, uninitialized state. More...
bool	HasType (HPS::Type in_mask) const
	This function indicates whether this Object has the given Type mask. More...
intptr_t	GetClassID () const
	Returns a unique identifier that is shared by all objects of the same class. More...
intptr_t	GetInstanceID () const
	Returns an identifier that can be used to identify which instance of a class an object is. More...

Static Public Member Functions
template<typename T >
static intptr_t	ClassID ()
	Unique identifier for this class. More...

Static Public Attributes
static const HPS::Type	staticType = HPS::Type::ComponentTreeItem

Detailed Description

The ComponentTreeItem class is a smart pointer which corresponds to an item or node in a tree object in a GUI toolkit, e.g., a TreeViewItem in WPF or an HTREEITEM in MFC.

This class must be derived from to facilitate tree creation in the various GUI toolkits. It is used to represent items in a component or model browser.

Constructor & Destructor Documentation

ComponentTreeItem() [1/5]

HPS::ComponentTreeItem::ComponentTreeItem

(

)

The default constructor creates an uninitialized ComponentTreeItem object.

The Type() function will return Type::None.

ComponentTreeItem() [2/5]

HPS::ComponentTreeItem::ComponentTreeItem

(

ComponentTreeItem const &

in_that

)

The copy constructor creates a ComponentTreeItem object that shares the underlying smart-pointer of the source ComponentTreeItem.

Parameters

in_that

The source ComponentTreeItem to copy.

ComponentTreeItem() [3/5]

HPS::ComponentTreeItem::ComponentTreeItem

(

ComponentTreeItem &&

in_that

)

The move constructor creates a ComponentTreeItem by transferring the underlying object of the rvalue reference to this ComponentTreeItem.

Parameters

in_that

An rvalue reference to a ComponentTreeItem to take the underlying object from.

ComponentTreeItem() [4/5]

HPS::ComponentTreeItem::ComponentTreeItem	(	ComponentTreePtr const &	in_tree,
		CADModel const &	in_cad_model
	)

This constructor creates a ComponentTreeItem suitable for acting as a root in a ComponentTree.

The CADModel provided to this constructor should be accessible from the Canvas and layer associated with the ComponentTree, otherwise an exception will be thrown.

Parameters

in_tree	The ComponentTree with which to associate this new root ComponentTreeItem.
in_cad_model	The CADModel for this root ComponentTreeItem.

See also

ComponentTree::SetRoot

ComponentTreeItem() [5/5]

HPS::ComponentTreeItem::ComponentTreeItem	(	ComponentTreePtr const &	in_tree,
		Component const &	in_component,
		ComponentTree::ItemType	in_type
	)

This constructor creates a ComponentTreeItem which is not suitable for acting as a root in a ComponentTree, but is suitable to be a ComponentTreeItem under the root of the ComponentTree.

This constructor should be the one invoked in the overridden AddChild function.

Parameters

in_tree	The ComponentTree with which to associate this new ComponentTreeItem.
in_component	The Component for this ComponentTreeItem. This value should come from the corresponding argument to AddChild.
in_type	The type of this ComponentTreeItem. This value should come from the corresponding argument to AddChild.

See also

AddChild

~ComponentTreeItem()

virtual HPS::ComponentTreeItem::~ComponentTreeItem ( )

virtual

Member Function Documentation

AddChild()

virtual ComponentTreeItemPtr HPS::ComponentTreeItem::AddChild ( Component const &  in_component, ComponentTree::ItemType  in_type  )

pure virtual

This function is used to create a new ComponentTreeItem to be the child of this ComponentTreeItem.

This function will be invoked if this ComponentTreeItem has children and Expand has been invoked on it. This function should contain any necessary calls to GUI toolkits to create the appropriate GUI elements. Additionally, since this function requires the creation of a derived ComponentTreeItem, that derived ComponentTreeItem should use the base constructor which takes the same arguments this function.

Parameters

in_component	The Component for this ComponentTreeItem. Should be passed to as the corresponding argument to the base constructor.
in_type	The type for this ComponentTreeItem. Should be passed to as the corresponding argument to the base constructor.

Returns

A newly created object derived from ComponentTreeItem.

Assign()

virtual void HPS::ComponentTreeItem::Assign ( ComponentTreeItem const &  in_that )

virtual

Share the underlying smart-pointer of the ComponentTreeItem source.

Parameters

in_that

The ComponentTreeItem source of the assignment.

Returns

A reference to this ComponentTreeItem.

ClassID()

template<typename T >

static intptr_t HPS::Object::ClassID ( )

inlinestaticinherited

Unique identifier for this class.

Note: this method uses construction of static objects. If used in a constructor, it should be used in the body not the initializer list.

Collapse()

virtual void HPS::ComponentTreeItem::Collapse ( )

virtual

This function should be invoked when this ComponentTreeItem needs to collapse.

If this function is overridden, the overriding function should invoke this base function. Additionally, this function will always release all children for this ComponentTreeItem when invoked.

Empty()

virtual bool HPS::Object::Empty ( ) const

inlinevirtualinherited

Indicates whether this object has any values set on it.

Returns

true if no values are set on this object, false otherwise.

Reimplemented in HPS::STL::ImportResultsKit, HPS::STL::ImportOptionsKit, HPS::OBJ::ImportResultsKit, HPS::OBJ::ImportOptionsKit, HPS::Hardcopy::File::ExportOptionsKit, HPS::Stream::ExportOptionsKit, HPS::Stream::ImportResultsKit, HPS::Stream::ImportOptionsKit, HPS::PointCloud::ImportOptionsKit, HPS::PointCloud::ImportResultsKit, HPS::UpdateOptionsKit, HPS::HighlightSearchOptionsKit, HPS::HighlightOptionsKit, HPS::SelectionOptionsKit, HPS::SearchOptionsKit, HPS::CutGeometryGatheringOptionsKit, HPS::ShapeKit, HPS::ShaderKit, HPS::Shader::ImportOptionsKit, HPS::ImageKit, HPS::Image::ImportOptionsKit, HPS::Image::ExportOptionsKit, HPS::TextureOptionsKit, HPS::LinePatternKit, HPS::LinePatternParallelKit, HPS::LinePatternOptionsKit, HPS::GlyphKit, HPS::ApplicationWindowOptionsKit, HPS::OffScreenWindowOptionsKit, HPS::StandAloneWindowOptionsKit, HPS::GridKit, HPS::PolygonKit, HPS::MeshKit, HPS::ShellKit, HPS::ShellRelationResultsKit, HPS::ShellRelationOptionsKit, HPS::ShellOptimizationOptionsKit, HPS::TextKit, HPS::EllipticalArcKit, HPS::EllipseKit, HPS::TrimKit, HPS::NURBSSurfaceKit, HPS::NURBSCurveKit, HPS::SpotlightKit, HPS::InfiniteLineKit, HPS::CuttingSectionKit, HPS::CircularWedgeKit, HPS::CircularArcKit, HPS::CircleKit, HPS::SphereKit, HPS::CylinderKit, HPS::DistantLightKit, HPS::MarkerKit, HPS::LineKit, HPS::AttributeLockKit, HPS::FontInfoState, HPS::WindowInfoKit, HPS::DebuggingKit, HPS::SubwindowKit, HPS::ContourLineKit, HPS::VisualEffectsKit, HPS::TransformMaskKit, HPS::PostProcessEffectsKit, HPS::DrawingAttributeKit, HPS::HiddenLineAttributeKit, HPS::PerformanceKit, HPS::NURBSSurfaceAttributeKit, HPS::MaterialKit, HPS::MaterialMappingKit, HPS::MatrixKit, HPS::CurveAttributeKit, HPS::EdgeAttributeKit, HPS::LineAttributeKit, HPS::TextAttributeKit, HPS::CuttingSectionAttributeKit, HPS::CylinderAttributeKit, HPS::LightingAttributeKit, HPS::SphereAttributeKit, HPS::MarkerAttributeKit, HPS::CullingKit, HPS::ColorInterpolationKit, HPS::TransparencyKit, HPS::SelectabilityKit, HPS::CameraKit, HPS::VisibilityKit, HPS::BoundingKit, HPS::SegmentOptimizationOptionsKit, HPS::Publish::ExportOptionsKit, HPS::Publish::TextFieldKit, HPS::Publish::SignatureFieldKit, HPS::Publish::DropDownListKit, HPS::Exchange::TessellationOptionsKit, HPS::Publish::ListBoxKit, HPS::Exchange::ExportSTEPOptionsKit, HPS::Exchange::ExportParasolidOptionsKit, HPS::Publish::RadioButtonKit, HPS::Exchange::ExportIGESOptionsKit, HPS::Exchange::ExportXMLOptionsKit, HPS::Publish::CheckBoxKit, HPS::Exchange::ExportU3DOptionsKit, HPS::Exchange::ExportSTLOptionsKit, HPS::Publish::ButtonKit, HPS::Exchange::ExportPRCOptionsKit, HPS::Publish::LinkKit, HPS::Exchange::ExportJTOptionsKit, HPS::Publish::SlideTableKit, HPS::Exchange::ExportACISOptionsKit, HPS::Publish::TableKit, HPS::Exchange::Export3MFOptionsKit, HPS::Publish::ImageKit, HPS::Publish::TextKit, HPS::Exchange::ModelFileImportOptionsKit, HPS::Publish::ViewKit, HPS::Exchange::TranslationOptionsKit, HPS::Publish::ArtworkKit, HPS::Publish::AnnotationKit, HPS::ComponentPath, HPS::Exchange::ImportOptionsKit, HPS::Parasolid::ExportOptionsKit, HPS::Exchange::NURBSConversionOptionsKit, HPS::Parasolid::LineTessellationKit, HPS::Exchange::Configuration, HPS::Publish::PageKit, HPS::Parasolid::FacetTessellationKit, HPS::Publish::DocumentKit, HPS::Parasolid::ImportOptionsKit, HPS::DWG::ImportOptionsKit, HPS::OOC::ImportOptionsKit, HPS::Sketchup::ImportOptionsKit, and HPS::Sketchup::ImportResultsKit.

Equals()

bool HPS::ComponentTreeItem::Equals

(

ComponentTreeItem const &

in_that

)

const

Check if the source ComponentTreeItem points to the same underlying impl as this ComponentTreeItem.

Parameters

in_that

The source ComponentTreeItem to compare to this ComponentTreeItem.

Returns

true if the objects reference the same impl, false otherwise.

Expand()

virtual void HPS::ComponentTreeItem::Expand ( )

virtual

This function should be invoked when this ComponentTreeItem needs to expand.

If this function is overridden, the overriding function should invoke this base function. Additionally, this function will always repopulate the children for this ComponentTreeItem when invoked.

GetClassID()

intptr_t HPS::Object::GetClassID ( ) const

inherited

Returns a unique identifier that is shared by all objects of the same class.

Returns

A unique value shared by all objects of the same class.

GetComponent()

Component HPS::ComponentTreeItem::GetComponent

(

)

const

Gets the Component for this ComponentTreeItem.

The type of the Component depends on the ComponentTree::ItemType for this ComponentTreeItem.

Returns

The Component for this ComponentTreeItem.

GetInstanceID()

intptr_t HPS::Object::GetInstanceID ( ) const

inherited

Returns an identifier that can be used to identify which instance of a class an object is.

Different keys and controls will return the same value if they are backed by the same database resource.

Returns

A value unique to an instance of an object and all objects that are backed by the same database resource.

GetItemType()

ComponentTree::ItemType HPS::ComponentTreeItem::GetItemType

(

)

const

Gets the item type for this ComponentTreeItem.

This is used to determine what type of data this ComponentTreeItem represents in the ComponentTree.

Returns

The item type for this ComponentTreeItem.

GetPath()

ComponentPath HPS::ComponentTreeItem::GetPath

(

)

const

Gets the ComponentPath corresponding to this ComponentTreeItem.

Returns

The ComponentPath corresponding to this ComponentTreeItem.

GetTitle()

UTF8 HPS::ComponentTreeItem::GetTitle

(

)

const

Gets the title for this ComponentTreeItem.

This is the text that should be displayed for this ComponentTreeItem in the ComponentTree.

Returns

The title for this ComponentTreeItem.

GetTree()

ComponentTreePtr HPS::ComponentTreeItem::GetTree

(

)

const

Gets the ComponentTree associated with this ComponentTreeItem.

This provides a means of accessing the derived ComponentTree by this ComponentTreeItem if necessary.

Returns

The ComponentTree associated with this ComponentTreeItem.

HasChildren()

bool HPS::ComponentTreeItem::HasChildren

(

)

const

Indicates whether this ComponentTreeItem has any children.

Returns

Whether this ComponentTreeItem has any children.

HasType()

bool HPS::Object::HasType ( HPS::Type  in_mask ) const

inherited

This function indicates whether this Object has the given Type mask.

Parameters

in_mask

The Type mask to check against this Object.

Returns

true if this Object has the given Type mask, false otherwise.

Hide()

void HPS::ComponentTreeItem::Hide

(

)

This function will cause this ComponentTreeItem to be hidden if it isn't already.

This will cause this item to be marked as hidden if it isn't already. Depending on the type of the ComponentTreeItem, sometimes a hide is nonsensical. In this case, no hide will be performed.

See also

OnHide

Highlight() [1/2]

void HPS::ComponentTreeItem::Highlight

(

size_t

in_highlight_options_index = 0

)

This function will cause this ComponentTreeItem to be highlighted with the nth option specified in the associated ComponentTree.

This will cause this item to be marked as highlighted if it isn't already. Depending on the type of the ComponentTreeItem, sometimes a highlight is nonsensical. In this case, no highlight will be performed.

Parameters

in_higlight_options_index

The index in the highlight options array held by the associated ComponentTree. Defaults to 0.

See also

OnHighlight

Highlight() [2/2]

void HPS::ComponentTreeItem::Highlight

(

HighlightOptionsKit const &

in_highlight_options

)

This function will cause this ComponentTreeItem to be highlighted with the options specified.

If the options requested is not part of the associated ComponentTree highlight options, it will be added to them. This will cause this item to be marked as highlighted if it isn't already. Depending on the type of the ComponentTreeItem, sometimes a highlight is nonsensical. In this case, no highlight will be performed.

Parameters

in_highlight_options

The highlight options used during highlighting

See also

OnHighlight

IsExpanded()

bool HPS::ComponentTreeItem::IsExpanded

(

)

const

Indicates whether this ComponentTreeItem is currently expanded.

Returns

Whether this ComponentTreeItem is currently expanded.

IsHidden()

bool HPS::ComponentTreeItem::IsHidden

(

)

const

Indicates whether this ComponentTreeItem is currently hidden.

This may mean that the Hide function on this ComponentTreeItem was invoked, or that the Component backing this ComponentTreeItem was hidden via ComponentPath::Hide or ComponentPath::Isolate.

Note

The state of this ComponentTreeItem may not yet mirror the state of the underlying ComponentPath as the notification is asynchronous. In order for this ComponentTreeItem to mirror the state of the underlying ComponentPath, a synchronous update needs to be performed on the associated view.

Returns

Whether this ComponentTreeItem is currently hidden.

See also

Hide

Show

Isolate

ComponentPath::Hide

ComponentPath::Show

ComponentPath::Isolate

IsHighlighted()

bool HPS::ComponentTreeItem::IsHighlighted

(

)

const

Indicates whether this ComponentTreeItem is currently highlighted with the options specified in the associated ComponentTree.

This may mean that the Highlight function on this ComponentTreeItem was invoked, or that the Component backing this ComponentTreeItem was highlighted by ComponentPath::Highlight.

Note

The state of this ComponentTreeItem may not yet mirror the state of the underlying ComponentPath as the notification is asynchronous. In order for this ComponentTreeItem to mirror the state of the underlying ComponentPath, a synchronous update needs to be performed on the associated view.

Returns

Whether this ComponentTreeItem is currently highlighted with the options specified in the associated ComponentTree.

See also

Highlight

Unhighlight

Isolate()

void HPS::ComponentTreeItem::Isolate

(

Component::Visibility

in_subtree_visibility = Component::Visibility::PreserveNone

)

This function will cause this ComponentTreeItem to be isolated, i.e., all other items will be hidden and this item will be shown.

This will cause this item to be marked as visible if it isn't already, and all other items to be marked as hidden. Depending on the type of the ComponentTreeItem, sometimes an isolate is nonsensical. In this case, no isolate will be performed.

Parameters

in_subtree_visibility

Dictates how Isolate will interact with the visibility of components in the tree under this item.

See also

OnHide

OnShow

ObjectType()

HPS::Type HPS::ComponentTreeItem::ObjectType ( ) const

inlinevirtual

Reimplemented from HPS::Object.

Here is the call graph for this function:

OnHide()

virtual void HPS::ComponentTreeItem::OnHide ( )

virtual

This function will be invoked when this ComponentTreeItem should be marked as hidden.

This hiding may have come as a result of the Hide or Isolate function on a ComponentTreeItem being invoked, or due to ComponentPath::Hide being invoked on the Component backing this ComponentTreeItem. This function is meant to be overridden to allow one to change the appearance of a hidden ComponentTreeItem, e.g., by graying the text or changing an icon, to signify this new state. If this function is overridden, the overriding function should invoke this base function.

OnHighlight()

virtual void HPS::ComponentTreeItem::OnHighlight ( HighlightOptionsKit const &  in_options )

virtual

This function will be invoked when this ComponentTreeItem should be marked as highlighted.

This highlighting may have come as a result of the Highlight function on a ComponentTreeItem being invoked, or due to ComponentPath::Highlight being invoked on the Component backing this ComponentTreeItem. This function is meant to be overridden to allow one to change the appearance of a highlighted ComponentTreeItem, e.g., by bolding the text or changing an icon, to signify this new state. If this function is overridden, the overriding function should invoke this base function.

Parameters

in_options

The HighlightOptionsKit for the associated highlight.

OnShow()

virtual void HPS::ComponentTreeItem::OnShow ( )

virtual

This function will be invoked when this ComponentTreeItem should be marked as visible.

This visibility may have come as a result of the Show or Isolate function on a ComponentTreeItem being invoked, or due to ComponentPath::Show or ComponentPath::Isolate being invoked on the Component backing this ComponentTreeItem. This function is meant to be overridden to allow one to change the appearance of a visible ComponentTreeItem, e.g., by no longer graying out the text or changing an icon, to signify this new state. If this function is overridden, the overriding function should invoke this base function.

OnUnhighlight()

virtual void HPS::ComponentTreeItem::OnUnhighlight ( HighlightOptionsKit const &  in_options )

virtual

This function will be invoked when this ComponentTreeItem should be marked as unhighlighted.

This unhighlighting may have come as a result of the Unhighlight function on a ComponentTreeItem being invoked, or due to ComponentPath::Unhighlight being invoked on the Component backing this ComponentTreeItem. This function is meant to be overridden to allow one to change the appearance of a unhighlighted ComponentTreeItem, e.g., by no longer bolding the text or changing an icon, to signify this new state. If this function is overridden, the overriding function should invoke this base function.

Parameters

in_options

The HighlightOptionsKit for the associated unhighlight.

operator!=()

bool HPS::ComponentTreeItem::operator!=

(

ComponentTreeItem const &

in_that

)

const

Check if the source ComponentTreeItem points to a different impl than this ComponentTreeItem.

Parameters

in_that

The source ComponentTreeItem to compare to this ComponentTreeItem.

Returns

true if the objects reference different impls, false otherwise.

operator=() [1/2]

ComponentTreeItem& HPS::ComponentTreeItem::operator=

(

ComponentTreeItem const &

in_that

)

Share the underlying smart-pointer of the ComponentTreeItem source.

Parameters

in_that

The ComponentTreeItem source of the assignment.

Returns

A reference to this ComponentTreeItem.

operator=() [2/2]

ComponentTreeItem& HPS::ComponentTreeItem::operator=

(

ComponentTreeItem &&

in_that

)

The move assignment operator transfers the underlying object of the rvalue reference to this ComponentTreeItem.

Parameters

in_that

An rvalue reference to a ComponentTreeItem to take the underlying object from.

Returns

A reference to this ComponentTreeItem.

operator==()

bool HPS::ComponentTreeItem::operator==

(

ComponentTreeItem const &

in_that

)

const

Check if the source ComponentTreeItem points to the same underlying impl as this ComponentTreeItem.

Parameters

in_that

The source ComponentTreeItem to compare to this ComponentTreeItem.

Returns

true if the objects reference the same impl, false otherwise.

ReExpand()

void HPS::ComponentTreeItem::ReExpand

(

)

Collapses this ComponentTreeItem and then re-expands the tree.

It will try to preserve the original expansion state, however, if the underlying component structure has changed, the resulting expansion may look different.

Reset()

virtual void HPS::Object::Reset ( )

virtualinherited

Resets this object to its initial, uninitialized state.

Reimplemented in HPS::EventHandler, HPS::EventDispatcher, HPS::World, HPS::HighlightSearchResults, HPS::HighlightSearchResultsIterator, HPS::SelectionResults, HPS::SelectionResultsIterator, HPS::FontSearchResults, HPS::FontSearchResultsIterator, HPS::SearchResults, and HPS::SearchResultsIterator.

Show()

void HPS::ComponentTreeItem::Show

(

Component::Visibility

in_subtree_visibility = Component::Visibility::PreserveNone

)

This function will cause this ComponentTreeItem to be visible if it isn't already.

This will cause this item to be marked as visible if it isn't already. Depending on the type of the ComponentTreeItem, sometimes a show is nonsensical. In this case, no show will be performed.

Parameters

in_subtree_visibility

Dictates how Isolate will interact with the visibility of components in the tree under this item.

See also

OnShow

Type()

virtual HPS::Type HPS::Object::Type ( ) const

virtualinherited

This function returns the true type of the underlying object.

This function is useful for finding the type of smart pointer objects that have been cast to more generic types.

Returns

The true type of the object in question.

Reimplemented in HPS::UpdateOptionsControl, HPS::HighlightControl, HPS::SelectionOptionsControl, HPS::OffScreenWindowOptionsControl, HPS::ApplicationWindowOptionsControl, HPS::StandAloneWindowOptionsControl, HPS::AttributeLockControl, HPS::WindowInfoControl, HPS::DebuggingControl, HPS::SubwindowControl, HPS::ContourLineControl, HPS::VisualEffectsControl, HPS::TransformMaskControl, HPS::PostProcessEffectsControl, HPS::DrawingAttributeControl, HPS::HiddenLineAttributeControl, HPS::PerformanceControl, HPS::NURBSSurfaceAttributeControl, HPS::ConditionControl, HPS::StyleControl, HPS::PortfolioControl, HPS::MaterialMappingControl, HPS::TextureMatrixControl, HPS::ModellingMatrixControl, HPS::CurveAttributeControl, HPS::EdgeAttributeControl, HPS::LineAttributeControl, HPS::TextAttributeControl, HPS::CuttingSectionAttributeControl, HPS::CylinderAttributeControl, HPS::LightingAttributeControl, HPS::SphereAttributeControl, HPS::MarkerAttributeControl, HPS::CullingControl, HPS::ColorInterpolationControl, HPS::TransparencyControl, HPS::SelectabilityControl, HPS::CameraControl, HPS::VisibilityControl, HPS::BoundingControl, HPS::Kit, and HPS::Control.

Unhighlight() [1/2]

void HPS::ComponentTreeItem::Unhighlight

(

size_t

in_highlight_options_index = 0

)

This function will cause this ComponentTreeItem to be unhighlighted with the nth option specified in the associated ComponentTree.

This will cause this item to be marked as unhighlighted if it isn't already. Depending on the type of the ComponentTreeItem, sometimes an unhighlight is nonsensical. In this case, no unhighlight will be performed.

Parameters

in_higlight_options_index

The index in the highlight options array held by the associated ComponentTree. Defaults to 0.

See also

OnUnhighlight

Unhighlight() [2/2]

void HPS::ComponentTreeItem::Unhighlight

(

HighlightOptionsKit const &

in_highlight_options

)

This function will cause this ComponentTreeItem to be unhighlighted with the options specified.

If the options requested is not part of the associated ComponentTree highlight options, it will be added to them. This will cause this item to be marked as unhighlighted if it isn't already. Depending on the type of the ComponentTreeItem, sometimes a highlight is nonsensical. In this case, no unhighlight will be performed.

Parameters

in_highlight_options

The highlight options used during unhighlighting

See also

OnUnhighlight

Member Data Documentation

staticType

const HPS::Type HPS::ComponentTreeItem::staticType = HPS::Type::ComponentTreeItem

static

---

The documentation for this class was generated from the following file:

• sprk.h
