HPS::MouseState Class Reference

The MouseState class represents the state of the mouse or similar pointer device for a particular event. More...

#include <hps.h>

Inheritance diagram for HPS::MouseState:

Collaboration diagram for HPS::MouseState:

Public Member Functions
	MouseState ()
	The default constructor creates an empty MouseState object. More...
	MouseState (MouseState const &in_that)
	The copy constructor creates a new MouseState object that contains the same settings as the source MouseState. More...
	MouseState (MouseState &&in_that)
	The move constructor creates a MouseState by transferring the underlying impl of the rvalue reference to this MouseState thereby avoiding a copy and allocation. More...
MouseState &	operator= (MouseState &&in_that)
	The move assignment operator transfers the underlying impl of the rvalue reference to this MouseState thereby avoiding a copy. More...
	~MouseState ()
HPS::Type	ObjectType () const
void	Assign (MouseState const &in_that)
	Copies the source MouseState into this MouseState. More...
MouseState &	operator= (MouseState const &in_that)
	Copies the source MouseState into this MouseState. More...
bool	Equals (MouseState const &in_that) const
	Check if the source MouseState is equivalent to this MouseState. More...
bool	operator== (MouseState const &in_that) const
	Check if the source MouseState is equivalent to this MouseState. More...
bool	operator!= (MouseState const &in_that) const
	Check if the source MouseState is not equivalent to this MouseState. More...
bool	HasAll (MouseButtons in_mouse_trigger, ModifierKeys in_modifier_trigger) const
	Checks if this MouseState has all of the specified properties. More...
void	Set (KeyArray const &in_path, MouseEvent const &in_event, WindowPoint const &in_point, MouseButtons in_buttons=MouseButtons(), ModifierKeys in_modifiers=ModifierKeys())
	Sets the properties of this MouseState. More...
HPS::MouseEvent	GetActiveEvent () const
	Get the active event for this MouseState. More...
HPS::WindowKey	GetEventSource () const
	Get the window which had focus when the mouse represented by this MouseState underwent the active action. More...
HPS::KeyArray	GetEventPath () const
	Get the relevant list of keys up to the window which had focus when the mouse represented by this MouseState underwent the active action. More...
MouseButtons	GetButtons () const
	Get the current state of the mouse buttons immediately after the active event. More...
WindowPoint	GetLocation () const
	Get the current mouse position. More...
ModifierKeys	GetModifierKeys () const
	Get an object representing the state of modifier keys for this MouseState. More...
void	SetActiveEvent (MouseEvent const &in_event)
	Sets the active event for this MouseState. More...
void	SetEventPath (KeyArray const &in_path)
	Sets the relevant list of keys up to the window which had focus for this mouse event. More...
void	SetButtons (MouseButtons in_buttons)
	Sets the current state of the mouse buttons immediately after the active event. More...
void	SetLocation (WindowPoint const &in_point)
	Sets the current mouse position. More...
void	SetModifierKeys (ModifierKeys in_modifiers)
	Sets an object representing the state of modifier keys for this MouseState. More...
virtual HPS::Type	Type () const
	This function returns the true type of the underlying object. More...
virtual bool	Empty () const
	Indicates whether this object has any values set on it. More...
virtual void	Reset ()
	Resets this object to its initial, uninitialized state. More...
bool	HasType (HPS::Type in_mask) const
	This function indicates whether this Object has the given Type mask. More...
intptr_t	GetClassID () const
	Returns a unique identifier that is shared by all objects of the same class. More...
intptr_t	GetInstanceID () const
	Returns an identifier that can be used to identify which instance of a class an object is. More...

Static Public Member Functions
template<typename T >
static intptr_t	ClassID ()
	Unique identifier for this class. More...

Static Public Attributes
static const HPS::Type	staticType = HPS::Type::MouseState

Detailed Description

The MouseState class represents the state of the mouse or similar pointer device for a particular event.

Constructor & Destructor Documentation

MouseState() [1/3]

HPS::MouseState::MouseState

(

)

The default constructor creates an empty MouseState object.

MouseState() [2/3]

HPS::MouseState::MouseState

(

MouseState const &

in_that

)

The copy constructor creates a new MouseState object that contains the same settings as the source MouseState.

Parameters

in_that

The source MouseState to copy.

MouseState() [3/3]

HPS::MouseState::MouseState

(

MouseState &&

in_that

)

The move constructor creates a MouseState by transferring the underlying impl of the rvalue reference to this MouseState thereby avoiding a copy and allocation.

Parameters

in_that

An rvalue reference to a MouseState to take the impl from.

~MouseState()

HPS::MouseState::~MouseState

(

)

Member Function Documentation

Assign()

void HPS::MouseState::Assign

(

MouseState const &

in_that

)

Copies the source MouseState into this MouseState.

Parameters

in_that

The source MouseState to copy.

ClassID()

template<typename T >

static intptr_t HPS::Object::ClassID ( )

inlinestaticinherited

Unique identifier for this class.

Note: this method uses construction of static objects. If used in a constructor, it should be used in the body not the initializer list.

Empty()

virtual bool HPS::Object::Empty ( ) const

inlinevirtualinherited

Indicates whether this object has any values set on it.

Returns

true if no values are set on this object, false otherwise.

Reimplemented in HPS::STL::ImportResultsKit, HPS::STL::ImportOptionsKit, HPS::OBJ::ImportResultsKit, HPS::OBJ::ImportOptionsKit, HPS::Hardcopy::File::ExportOptionsKit, HPS::Stream::ExportOptionsKit, HPS::Stream::ImportResultsKit, HPS::Stream::ImportOptionsKit, HPS::PointCloud::ImportOptionsKit, HPS::PointCloud::ImportResultsKit, HPS::UpdateOptionsKit, HPS::HighlightSearchOptionsKit, HPS::HighlightOptionsKit, HPS::SelectionOptionsKit, HPS::SearchOptionsKit, HPS::CutGeometryGatheringOptionsKit, HPS::ShapeKit, HPS::ShaderKit, HPS::Shader::ImportOptionsKit, HPS::ImageKit, HPS::Image::ImportOptionsKit, HPS::Image::ExportOptionsKit, HPS::TextureOptionsKit, HPS::LinePatternKit, HPS::LinePatternParallelKit, HPS::LinePatternOptionsKit, HPS::GlyphKit, HPS::ApplicationWindowOptionsKit, HPS::OffScreenWindowOptionsKit, HPS::StandAloneWindowOptionsKit, HPS::GridKit, HPS::PolygonKit, HPS::MeshKit, HPS::ShellKit, HPS::ShellRelationResultsKit, HPS::ShellRelationOptionsKit, HPS::ShellOptimizationOptionsKit, HPS::TextKit, HPS::EllipticalArcKit, HPS::EllipseKit, HPS::TrimKit, HPS::NURBSSurfaceKit, HPS::NURBSCurveKit, HPS::SpotlightKit, HPS::InfiniteLineKit, HPS::CuttingSectionKit, HPS::CircularWedgeKit, HPS::CircularArcKit, HPS::CircleKit, HPS::SphereKit, HPS::CylinderKit, HPS::DistantLightKit, HPS::MarkerKit, HPS::LineKit, HPS::AttributeLockKit, HPS::FontInfoState, HPS::WindowInfoKit, HPS::DebuggingKit, HPS::SubwindowKit, HPS::ContourLineKit, HPS::VisualEffectsKit, HPS::TransformMaskKit, HPS::PostProcessEffectsKit, HPS::DrawingAttributeKit, HPS::HiddenLineAttributeKit, HPS::PerformanceKit, HPS::NURBSSurfaceAttributeKit, HPS::MaterialKit, HPS::MaterialMappingKit, HPS::MatrixKit, HPS::CurveAttributeKit, HPS::EdgeAttributeKit, HPS::LineAttributeKit, HPS::TextAttributeKit, HPS::CuttingSectionAttributeKit, HPS::CylinderAttributeKit, HPS::LightingAttributeKit, HPS::SphereAttributeKit, HPS::MarkerAttributeKit, HPS::CullingKit, HPS::ColorInterpolationKit, HPS::TransparencyKit, HPS::SelectabilityKit, HPS::CameraKit, HPS::VisibilityKit, HPS::BoundingKit, HPS::SegmentOptimizationOptionsKit, HPS::Publish::ExportOptionsKit, HPS::Publish::TextFieldKit, HPS::Publish::SignatureFieldKit, HPS::Publish::DropDownListKit, HPS::Exchange::TessellationOptionsKit, HPS::Publish::ListBoxKit, HPS::Exchange::ExportSTEPOptionsKit, HPS::Exchange::ExportParasolidOptionsKit, HPS::Publish::RadioButtonKit, HPS::Exchange::ExportIGESOptionsKit, HPS::Exchange::ExportXMLOptionsKit, HPS::Publish::CheckBoxKit, HPS::Exchange::ExportU3DOptionsKit, HPS::Exchange::ExportSTLOptionsKit, HPS::Publish::ButtonKit, HPS::Exchange::ExportPRCOptionsKit, HPS::Publish::LinkKit, HPS::Exchange::ExportJTOptionsKit, HPS::Publish::SlideTableKit, HPS::Exchange::ExportACISOptionsKit, HPS::Publish::TableKit, HPS::Exchange::Export3MFOptionsKit, HPS::Publish::ImageKit, HPS::Publish::TextKit, HPS::Exchange::ModelFileImportOptionsKit, HPS::Publish::ViewKit, HPS::Exchange::TranslationOptionsKit, HPS::Publish::ArtworkKit, HPS::Publish::AnnotationKit, HPS::ComponentPath, HPS::Exchange::ImportOptionsKit, HPS::Parasolid::ExportOptionsKit, HPS::Exchange::NURBSConversionOptionsKit, HPS::Parasolid::LineTessellationKit, HPS::Exchange::Configuration, HPS::Publish::PageKit, HPS::Parasolid::FacetTessellationKit, HPS::Publish::DocumentKit, HPS::Parasolid::ImportOptionsKit, HPS::DWG::ImportOptionsKit, HPS::OOC::ImportOptionsKit, HPS::Sketchup::ImportOptionsKit, and HPS::Sketchup::ImportResultsKit.

Equals()

bool HPS::MouseState::Equals

(

MouseState const &

in_that

)

const

Check if the source MouseState is equivalent to this MouseState.

Parameters

in_kit

The source MouseState to compare to this MouseState.

Returns

true if the objects are equivalent, false otherwise.

GetActiveEvent()

HPS::MouseEvent HPS::MouseState::GetActiveEvent

(

)

const

Get the active event for this MouseState.

This will throw an exception if there is no active action for this MouseState.

Returns

The action for this MouseState.

GetButtons()

MouseButtons HPS::MouseState::GetButtons

(

)

const

Get the current state of the mouse buttons immediately after the active event.

Returns

The state of the mouse buttons.

GetClassID()

intptr_t HPS::Object::GetClassID ( ) const

inherited

Returns a unique identifier that is shared by all objects of the same class.

Returns

A unique value shared by all objects of the same class.

GetEventPath()

HPS::KeyArray HPS::MouseState::GetEventPath

(

)

const

Get the relevant list of keys up to the window which had focus when the mouse represented by this MouseState underwent the active action.

This will throw an exception if there is no event path for this MouseState.

Returns

The relevant list of keys up to the window which had focus when the mouse event represented by this MouseState underwent the active action.

GetEventSource()

HPS::WindowKey HPS::MouseState::GetEventSource

(

)

const

Get the window which had focus when the mouse represented by this MouseState underwent the active action.

This will throw an exception if there is no event source for this MouseState.

Returns

The window which had focus when the mouse represented by this MouseState underwent the active action.

GetInstanceID()

intptr_t HPS::Object::GetInstanceID ( ) const

inherited

Returns an identifier that can be used to identify which instance of a class an object is.

Different keys and controls will return the same value if they are backed by the same database resource.

Returns

A value unique to an instance of an object and all objects that are backed by the same database resource.

GetLocation()

WindowPoint HPS::MouseState::GetLocation

(

)

const

Get the current mouse position.

Returns

The location, in window space of the mouse cursor.

GetModifierKeys()

ModifierKeys HPS::MouseState::GetModifierKeys

(

)

const

Get an object representing the state of modifier keys for this MouseState.

Returns

An object representing the state of modifier keys.

HasAll()

bool HPS::MouseState::HasAll	(	MouseButtons	in_mouse_trigger,
		ModifierKeys	in_modifier_trigger
	)		const

Checks if this MouseState has all of the specified properties.

Parameters

in_mouse_trigger	The mouse button properties to test for.
in_modifier_trigger	The modifier keys properties to test for.

Returns

true if this MouseState has all of the specified properties, false otherwise.

Here is the caller graph for this function:

HasType()

bool HPS::Object::HasType ( HPS::Type  in_mask ) const

inherited

This function indicates whether this Object has the given Type mask.

Parameters

in_mask

The Type mask to check against this Object.

Returns

true if this Object has the given Type mask, false otherwise.

ObjectType()

HPS::Type HPS::MouseState::ObjectType ( ) const

inlinevirtual

Reimplemented from HPS::Object.

Here is the call graph for this function:

operator!=()

bool HPS::MouseState::operator!=

(

MouseState const &

in_that

)

const

Check if the source MouseState is not equivalent to this MouseState.

Parameters

in_kit

The source MouseState to compare to this MouseState.

Returns

true if the objects are not equivalent, false otherwise.

operator=() [1/2]

MouseState& HPS::MouseState::operator=

(

MouseState &&

in_that

)

The move assignment operator transfers the underlying impl of the rvalue reference to this MouseState thereby avoiding a copy.

Parameters

in_that

An rvalue reference to a MouseState to take the impl from.

Returns

A reference to this MouseState.

operator=() [2/2]

MouseState& HPS::MouseState::operator=

(

MouseState const &

in_that

)

Copies the source MouseState into this MouseState.

Parameters

in_that

The source MouseState to copy.

Returns

A reference to this MouseState.

operator==()

bool HPS::MouseState::operator==

(

MouseState const &

in_that

)

const

Check if the source MouseState is equivalent to this MouseState.

Parameters

in_kit

The source MouseState to compare to this MouseState.

Returns

true if the objects are equivalent, false otherwise.

Reset()

virtual void HPS::Object::Reset ( )

virtualinherited

Resets this object to its initial, uninitialized state.

Reimplemented in HPS::EventHandler, HPS::EventDispatcher, HPS::World, HPS::HighlightSearchResults, HPS::HighlightSearchResultsIterator, HPS::SelectionResults, HPS::SelectionResultsIterator, HPS::FontSearchResults, HPS::FontSearchResultsIterator, HPS::SearchResults, and HPS::SearchResultsIterator.

Set()

void HPS::MouseState::Set	(	KeyArray const &	in_path,
		MouseEvent const &	in_event,
		WindowPoint const &	in_point,
		MouseButtons	in_buttons = MouseButtons(),
		ModifierKeys	in_modifiers = ModifierKeys()
	)

Sets the properties of this MouseState.

Parameters

in_path	The list of keys up to the window which had focus for this mouse event.
in_event	The mouse event.
in_point	The location, in window space of the mouse cursor for this mouse event.
in_buttons	The state of the mouse buttons immediately after this mouse event.
in_modifiers	The state of modifier keys for this mouse event.

SetActiveEvent()

void HPS::MouseState::SetActiveEvent

(

MouseEvent const &

in_event

)

Sets the active event for this MouseState.

Parameters

in_event

The action for this MouseState.

SetButtons()

void HPS::MouseState::SetButtons

(

MouseButtons

in_buttons

)

Sets the current state of the mouse buttons immediately after the active event.

Parameters

in_buttons

The state of the mouse buttons.

SetEventPath()

void HPS::MouseState::SetEventPath

(

KeyArray const &

in_path

)

Sets the relevant list of keys up to the window which had focus for this mouse event.

Parameters

in_path

The relevant list of keys up to the window which had focus when the mouse event represented by this MouseState underwent the active action.

SetLocation()

void HPS::MouseState::SetLocation

(

WindowPoint const &

in_point

)

Sets the current mouse position.

Parameters

in_point

The location, in window space of the mouse cursor.

SetModifierKeys()

void HPS::MouseState::SetModifierKeys

(

ModifierKeys

in_modifiers

)

Sets an object representing the state of modifier keys for this MouseState.

Parameters

in_modifiers

An object representing the state of modifier keys.

Type()

virtual HPS::Type HPS::Object::Type ( ) const

virtualinherited

This function returns the true type of the underlying object.

This function is useful for finding the type of smart pointer objects that have been cast to more generic types.

Returns

The true type of the object in question.

Reimplemented in HPS::UpdateOptionsControl, HPS::HighlightControl, HPS::SelectionOptionsControl, HPS::OffScreenWindowOptionsControl, HPS::ApplicationWindowOptionsControl, HPS::StandAloneWindowOptionsControl, HPS::AttributeLockControl, HPS::WindowInfoControl, HPS::DebuggingControl, HPS::SubwindowControl, HPS::ContourLineControl, HPS::VisualEffectsControl, HPS::TransformMaskControl, HPS::PostProcessEffectsControl, HPS::DrawingAttributeControl, HPS::HiddenLineAttributeControl, HPS::PerformanceControl, HPS::NURBSSurfaceAttributeControl, HPS::ConditionControl, HPS::StyleControl, HPS::PortfolioControl, HPS::MaterialMappingControl, HPS::TextureMatrixControl, HPS::ModellingMatrixControl, HPS::CurveAttributeControl, HPS::EdgeAttributeControl, HPS::LineAttributeControl, HPS::TextAttributeControl, HPS::CuttingSectionAttributeControl, HPS::CylinderAttributeControl, HPS::LightingAttributeControl, HPS::SphereAttributeControl, HPS::MarkerAttributeControl, HPS::CullingControl, HPS::ColorInterpolationControl, HPS::TransparencyControl, HPS::SelectabilityControl, HPS::CameraControl, HPS::VisibilityControl, HPS::BoundingControl, HPS::Kit, and HPS::Control.

Member Data Documentation

staticType

const HPS::Type HPS::MouseState::staticType = HPS::Type::MouseState

static

---

The documentation for this class was generated from the following file:

• hps.h
