HPS::TreeContext Class Reference

The TreeContext class is a user space object. More...

#include <hps.h>

Inheritance diagram for HPS::TreeContext:

Collaboration diagram for HPS::TreeContext:

Public Member Functions
	TreeContext (bool in_create=true)
	The default constructor creates a new TreeContext object. More...
	TreeContext (TreeContext const &in_that)
	The copy constructor shares a TreeContext object. More...
	TreeContext (TreeContext &&in_that)
	The move constructor creates a new TreeContext by transferring the underlying impl of the rvalue reference to this TreeContext thereby avoiding a copy and allocation. More...
TreeContext &	operator= (TreeContext &&in_that)
	The move assignment operator transfers the underlying impl of the rvalue reference to this TreeContext thereby avoiding a copy. More...
virtual	~TreeContext ()
	The destructor cleans up the tree context created by the constructor. More...
HPS::Type	ObjectType () const
TreeContext &	operator= (TreeContext const &in_that)
	Shares the source TreeContext. More...
bool	Equals (TreeContext const &in_that) const
	Check if the source TreeContext is the same as this TreeContext. More...
bool	operator== (TreeContext const &in_that) const
	Check if the source TreeContext is the same as this TreeContext. More...
bool	operator!= (TreeContext const &in_that) const
	Check if the source TreeContext is not the same as this TreeContext. More...
virtual HPS::Type	Type () const
	This function returns the true type of the underlying object. More...
virtual bool	Empty () const
	Indicates whether this object has any values set on it. More...
virtual void	Reset ()
	Resets this object to its initial, uninitialized state. More...
bool	HasType (HPS::Type in_mask) const
	This function indicates whether this Object has the given Type mask. More...
intptr_t	GetClassID () const
	Returns a unique identifier that is shared by all objects of the same class. More...
intptr_t	GetInstanceID () const
	Returns an identifier that can be used to identify which instance of a class an object is. More...

Static Public Member Functions
template<typename T >
static intptr_t	ClassID ()
	Unique identifier for this class. More...

Static Public Attributes
static const HPS::Type	staticType = HPS::Type::TreeContext

Detailed Description

The TreeContext class is a user space object.

It contains a spatial partition used for shell selection and shell relation computations. If many such operations will be performed without modifying the segment tree, using the same TreeContext for all of them can be a significant optimization. If a TreeContext is not specified, a new one is computed internally each time.

Constructor & Destructor Documentation

TreeContext() [1/3]

HPS::TreeContext::TreeContext

(

bool

in_create = true

)

The default constructor creates a new TreeContext object.

Parameters

in_create

whether to create the underlying spatial tree context.

TreeContext() [2/3]

HPS::TreeContext::TreeContext

(

TreeContext const &

in_that

)

The copy constructor shares a TreeContext object.

Parameters

in_that

The source TreeContext to share.

TreeContext() [3/3]

HPS::TreeContext::TreeContext

(

TreeContext &&

in_that

)

The move constructor creates a new TreeContext by transferring the underlying impl of the rvalue reference to this TreeContext thereby avoiding a copy and allocation.

Parameters

in_that

An rvalue reference to a TreeContext to take the impl from.

~TreeContext()

virtual HPS::TreeContext::~TreeContext ( )

virtual

The destructor cleans up the tree context created by the constructor.

Member Function Documentation

ClassID()

template<typename T >

static intptr_t HPS::Object::ClassID ( )

inlinestaticinherited

Unique identifier for this class.

Note: this method uses construction of static objects. If used in a constructor, it should be used in the body not the initializer list.

Empty()

virtual bool HPS::Object::Empty ( ) const

inlinevirtualinherited

Indicates whether this object has any values set on it.

Returns

true if no values are set on this object, false otherwise.

Reimplemented in HPS::STL::ImportResultsKit, HPS::STL::ImportOptionsKit, HPS::OBJ::ImportResultsKit, HPS::OBJ::ImportOptionsKit, HPS::Hardcopy::File::ExportOptionsKit, HPS::Stream::ExportOptionsKit, HPS::Stream::ImportResultsKit, HPS::Stream::ImportOptionsKit, HPS::PointCloud::ImportOptionsKit, HPS::PointCloud::ImportResultsKit, HPS::UpdateOptionsKit, HPS::HighlightSearchOptionsKit, HPS::HighlightOptionsKit, HPS::SelectionOptionsKit, HPS::SearchOptionsKit, HPS::CutGeometryGatheringOptionsKit, HPS::ShapeKit, HPS::ShaderKit, HPS::Shader::ImportOptionsKit, HPS::ImageKit, HPS::Image::ImportOptionsKit, HPS::Image::ExportOptionsKit, HPS::TextureOptionsKit, HPS::LinePatternKit, HPS::LinePatternParallelKit, HPS::LinePatternOptionsKit, HPS::GlyphKit, HPS::ApplicationWindowOptionsKit, HPS::OffScreenWindowOptionsKit, HPS::StandAloneWindowOptionsKit, HPS::GridKit, HPS::PolygonKit, HPS::MeshKit, HPS::ShellKit, HPS::ShellRelationResultsKit, HPS::ShellRelationOptionsKit, HPS::ShellOptimizationOptionsKit, HPS::TextKit, HPS::EllipticalArcKit, HPS::EllipseKit, HPS::TrimKit, HPS::NURBSSurfaceKit, HPS::NURBSCurveKit, HPS::SpotlightKit, HPS::InfiniteLineKit, HPS::CuttingSectionKit, HPS::CircularWedgeKit, HPS::CircularArcKit, HPS::CircleKit, HPS::SphereKit, HPS::CylinderKit, HPS::DistantLightKit, HPS::MarkerKit, HPS::LineKit, HPS::AttributeLockKit, HPS::FontInfoState, HPS::WindowInfoKit, HPS::DebuggingKit, HPS::SubwindowKit, HPS::ContourLineKit, HPS::VisualEffectsKit, HPS::TransformMaskKit, HPS::PostProcessEffectsKit, HPS::DrawingAttributeKit, HPS::HiddenLineAttributeKit, HPS::PerformanceKit, HPS::NURBSSurfaceAttributeKit, HPS::MaterialKit, HPS::MaterialMappingKit, HPS::MatrixKit, HPS::CurveAttributeKit, HPS::EdgeAttributeKit, HPS::LineAttributeKit, HPS::TextAttributeKit, HPS::CuttingSectionAttributeKit, HPS::CylinderAttributeKit, HPS::LightingAttributeKit, HPS::SphereAttributeKit, HPS::MarkerAttributeKit, HPS::CullingKit, HPS::ColorInterpolationKit, HPS::TransparencyKit, HPS::SelectabilityKit, HPS::CameraKit, HPS::VisibilityKit, HPS::BoundingKit, HPS::SegmentOptimizationOptionsKit, HPS::Publish::ExportOptionsKit, HPS::Publish::TextFieldKit, HPS::Publish::SignatureFieldKit, HPS::Publish::DropDownListKit, HPS::Exchange::TessellationOptionsKit, HPS::Publish::ListBoxKit, HPS::Exchange::ExportSTEPOptionsKit, HPS::Exchange::ExportParasolidOptionsKit, HPS::Publish::RadioButtonKit, HPS::Exchange::ExportIGESOptionsKit, HPS::Exchange::ExportXMLOptionsKit, HPS::Publish::CheckBoxKit, HPS::Exchange::ExportU3DOptionsKit, HPS::Exchange::ExportSTLOptionsKit, HPS::Publish::ButtonKit, HPS::Exchange::ExportPRCOptionsKit, HPS::Publish::LinkKit, HPS::Exchange::ExportJTOptionsKit, HPS::Publish::SlideTableKit, HPS::Exchange::ExportACISOptionsKit, HPS::Publish::TableKit, HPS::Exchange::Export3MFOptionsKit, HPS::Publish::ImageKit, HPS::Publish::TextKit, HPS::Exchange::ModelFileImportOptionsKit, HPS::Publish::ViewKit, HPS::Exchange::TranslationOptionsKit, HPS::Publish::ArtworkKit, HPS::Publish::AnnotationKit, HPS::ComponentPath, HPS::Exchange::ImportOptionsKit, HPS::Parasolid::ExportOptionsKit, HPS::Exchange::NURBSConversionOptionsKit, HPS::Parasolid::LineTessellationKit, HPS::Exchange::Configuration, HPS::Publish::PageKit, HPS::Parasolid::FacetTessellationKit, HPS::Publish::DocumentKit, HPS::Parasolid::ImportOptionsKit, HPS::DWG::ImportOptionsKit, HPS::OOC::ImportOptionsKit, HPS::Sketchup::ImportOptionsKit, and HPS::Sketchup::ImportResultsKit.

Equals()

bool HPS::TreeContext::Equals

(

TreeContext const &

in_that

)

const

Check if the source TreeContext is the same as this TreeContext.

Parameters

in_kit

The source TreeContext to compare to this TreeContext.

Returns

true if the objects are identical, false otherwise.

GetClassID()

intptr_t HPS::Object::GetClassID ( ) const

inherited

Returns a unique identifier that is shared by all objects of the same class.

Returns

A unique value shared by all objects of the same class.

GetInstanceID()

intptr_t HPS::Object::GetInstanceID ( ) const

inherited

Returns an identifier that can be used to identify which instance of a class an object is.

Different keys and controls will return the same value if they are backed by the same database resource.

Returns

A value unique to an instance of an object and all objects that are backed by the same database resource.

HasType()

bool HPS::Object::HasType ( HPS::Type  in_mask ) const

inherited

This function indicates whether this Object has the given Type mask.

Parameters

in_mask

The Type mask to check against this Object.

Returns

true if this Object has the given Type mask, false otherwise.

ObjectType()

HPS::Type HPS::TreeContext::ObjectType ( ) const

inlinevirtual

Reimplemented from HPS::Object.

Here is the call graph for this function:

operator!=()

bool HPS::TreeContext::operator!=

(

TreeContext const &

in_that

)

const

Check if the source TreeContext is not the same as this TreeContext.

Parameters

in_kit

The source TreeContext to compare to this TreeContext.

Returns

true if the objects are not identical, false otherwise.

operator=() [1/2]

TreeContext& HPS::TreeContext::operator=

(

TreeContext &&

in_that

)

The move assignment operator transfers the underlying impl of the rvalue reference to this TreeContext thereby avoiding a copy.

Parameters

in_that

An rvalue reference to a TreeContext to take the impl from.

Returns

A reference to this TreeContext.

operator=() [2/2]

TreeContext& HPS::TreeContext::operator=

(

TreeContext const &

in_that

)

Shares the source TreeContext.

Parameters

in_kit

The source TreeContext to share.

Returns

A reference to this TreeContext.

operator==()

bool HPS::TreeContext::operator==

(

TreeContext const &

in_that

)

const

Check if the source TreeContext is the same as this TreeContext.

Parameters

in_kit

The source TreeContext to compare to this TreeContext.

Returns

true if the objects are identical, false otherwise.

Reset()

virtual void HPS::Object::Reset ( )

virtualinherited

Resets this object to its initial, uninitialized state.

Reimplemented in HPS::EventHandler, HPS::EventDispatcher, HPS::World, HPS::HighlightSearchResults, HPS::HighlightSearchResultsIterator, HPS::SelectionResults, HPS::SelectionResultsIterator, HPS::FontSearchResults, HPS::FontSearchResultsIterator, HPS::SearchResults, and HPS::SearchResultsIterator.

Type()

virtual HPS::Type HPS::Object::Type ( ) const

virtualinherited

This function returns the true type of the underlying object.

This function is useful for finding the type of smart pointer objects that have been cast to more generic types.

Returns

The true type of the object in question.

Reimplemented in HPS::UpdateOptionsControl, HPS::HighlightControl, HPS::SelectionOptionsControl, HPS::OffScreenWindowOptionsControl, HPS::ApplicationWindowOptionsControl, HPS::StandAloneWindowOptionsControl, HPS::AttributeLockControl, HPS::WindowInfoControl, HPS::DebuggingControl, HPS::SubwindowControl, HPS::ContourLineControl, HPS::VisualEffectsControl, HPS::TransformMaskControl, HPS::PostProcessEffectsControl, HPS::DrawingAttributeControl, HPS::HiddenLineAttributeControl, HPS::PerformanceControl, HPS::NURBSSurfaceAttributeControl, HPS::ConditionControl, HPS::StyleControl, HPS::PortfolioControl, HPS::MaterialMappingControl, HPS::TextureMatrixControl, HPS::ModellingMatrixControl, HPS::CurveAttributeControl, HPS::EdgeAttributeControl, HPS::LineAttributeControl, HPS::TextAttributeControl, HPS::CuttingSectionAttributeControl, HPS::CylinderAttributeControl, HPS::LightingAttributeControl, HPS::SphereAttributeControl, HPS::MarkerAttributeControl, HPS::CullingControl, HPS::ColorInterpolationControl, HPS::TransparencyControl, HPS::SelectabilityControl, HPS::CameraControl, HPS::VisibilityControl, HPS::BoundingControl, HPS::Kit, and HPS::Control.

Member Data Documentation

staticType

const HPS::Type HPS::TreeContext::staticType = HPS::Type::TreeContext

static

---

The documentation for this class was generated from the following file:

• hps.h
