HPS::KeyPath Class Reference

The KeyPath contains an array of keys, organized from leaf to root. More...

#include <hps.h>

Inheritance diagram for HPS::KeyPath:

Collaboration diagram for HPS::KeyPath:

Public Member Functions
	KeyPath ()
	Creates an uninitialized key path that refers to no database objects. More...
	KeyPath (KeyArray const &in_path)
	Creates a new KeyPath object based on the supplied path. More...
	KeyPath (size_t in_path_count, Key const in_path [])
	Creates a new KeyPath object based on the supplied path. More...
	KeyPath (KeyPath const &in_that)
	Copies in_that into this key path. More...
	KeyPath (KeyPath &&in_that)
	The move constructor creates a KeyPath by transferring the underlying impl of the rvalue reference to this KeyPath thereby avoiding a copy and allocation. More...
KeyPath &	operator= (KeyPath &&in_that)
	The move assignment operator transfers the underlying impl of the rvalue reference to this KeyPath thereby avoiding a copy. More...
virtual	~KeyPath ()
	Releases a reference to the database object this object is tied to. More...
HPS::Type	ObjectType () const
KeyPath &	operator+= (Key const &in_key)
	Appends the supplied Key into this object. More...
KeyPath &	operator+= (KeyPath const &in_key_path)
	Appends the supplied KeyPath into this object. More...
KeyPath &	operator+= (KeyArray const &in_key_array)
	Appends the supplied KeyArray into this object. More...
KeyPath &	Append (Key const &in_key)
	Appends the supplied Key into this object. More...
KeyPath &	Append (KeyPath const &in_key_path)
	Appends the supplied key into this object. More...
KeyPath &	Append (KeyArray const &in_key_array)
	Appends the supplied key into this object. More...
KeyPath &	operator= (KeyPath const &in_that)
	Copies the supplied path into this object. More...
KeyPath &	operator= (KeyArray const &in_path)
	Copies an array of keys into this object. More...
void	Set (KeyPath const &in_that)
	Copies the supplied path into this object. More...
bool	Equals (KeyPath const &in_that) const
	Check if the source KeyPath is equivalent to this object. More...
bool	operator!= (KeyPath const &in_that) const
	Check if the source KeyPath is not equivalent to this object. More...
bool	operator== (KeyPath const &in_that) const
	Check if the source KeyPath is equivalent to this object. More...
KeyPath &	SetKeys (KeyArray const &in_keys)
	Copies an array of keys into this object. More...
KeyPath &	SetKeys (size_t in_key_count, Key const in_keys [])
	Copies an array of keys into this object. More...
KeyPath &	UnsetKeys ()
	Removes the keys defining this key path. More...
bool	ShowKeys (KeyArray &out_keys) const
	Shows the keys defining this key path. More...
bool	ConvertCoordinate (Coordinate::Space in_space, Point const &in_point, Coordinate::Space in_output_space, Point &out_point) const
	Converts a point from one coordinate space to another using the transforms along this key path. More...
bool	ConvertCoordinate (Coordinate::Space in_space, PointArray const &in_points, Coordinate::Space in_output_space, PointArray &out_points) const
	Converts a point from one coordinate space to another using the transforms along this key path. More...
bool	ComputeTextExtent (char const *in_text, float &out_xfrac, float &out_yfrac) const
	Computes the extents of the specified text string based on the effective text attributes along this key path. More...
bool	ComputeExtent (Rectangle &out_extent) const
	Computes a tight 2D extents box around the geometry contained in this key path. More...
bool	ComputeExtent (HPS::VisibilityKit const &in_vis, Rectangle &out_extent) const
	Computes a tight 2D extents box around the geometry contained in this key path. More...
bool	ComputeExtent (HPS::Extent::ClipRegion in_clip, Rectangle &out_extent) const
	Computes a tight 2D extents box around the geometry contained in this key path. More...
bool	ComputeExtent (HPS::VisibilityKit const &in_vis, HPS::Extent::ClipRegion in_clip, Rectangle &out_extent) const
	Computes a tight 2D extents box around the geometry contained in this key path. More...
bool	ComputeTransform (Coordinate::Space in_space, Coordinate::Space in_output_space, HPS::MatrixKit &out_matrix) const
	Computes the matrix which transforms objects from the input space to the output space along this key path. More...
bool	ShowNetVisibility (VisibilityKit &out_kit) const
	Shows the net visibility attribute settings along this key path. More...
bool	ShowNetBounding (BoundingKit &out_kit) const
	Shows the net bounding along this key path. More...
bool	ShowNetCamera (CameraKit &out_kit) const
	Shows the net camera attribute settings along this key path. More...
bool	ShowNetColorInterpolation (ColorInterpolationKit &out_kit) const
	Shows the net color interpolation attribute settings along this key path. More...
bool	ShowNetContourLine (ContourLineKit &out_kit) const
	Shows the net contour line attribute settings along this key path. More...
bool	ShowNetPerformance (PerformanceKit &out_kit) const
	Shows the net performance attribute settings along this key path. More...
bool	ShowNetHiddenLineAttribute (HiddenLineAttributeKit &out_kit) const
	Shows the net hidden line attribute settings along this key path. More...
bool	ShowNetDrawingAttribute (DrawingAttributeKit &out_kit) const
	Shows the net drawing attribute settings along this key path. More...
bool	ShowNetSelectability (SelectabilityKit &out_kit) const
	Shows the net selectability attribute settings along this key path. More...
bool	ShowNetMarkerAttribute (MarkerAttributeKit &out_kit) const
	Shows the net marker attribute settings along this key path. More...
bool	ShowNetSphereAttribute (SphereAttributeKit &out_kit) const
	Shows the net sphere attribute settings along this key path. More...
bool	ShowNetLightingAttribute (LightingAttributeKit &out_kit) const
	Shows the net lighting attribute settings along this key path. More...
bool	ShowNetCylinderAttribute (CylinderAttributeKit &out_kit) const
	Shows the net cylinder attribute settings along this key path. More...
bool	ShowNetCuttingSectionAttribute (CuttingSectionAttributeKit &out_kit) const
	Shows the net cutting section attribute settings along this key path. More...
bool	ShowNetTextAttribute (TextAttributeKit &out_kit) const
	Shows the net text attribute settings along this key path. More...
bool	ShowNetLineAttribute (LineAttributeKit &out_kit) const
	Shows the net line attribute settings along this key path. More...
bool	ShowNetEdgeAttribute (EdgeAttributeKit &out_kit) const
	Shows the net edge attribute settings along this key path. More...
bool	ShowNetCurveAttribute (CurveAttributeKit &out_kit) const
	Shows the net curve attribute settings along this key path. More...
bool	ShowNetModellingMatrix (MatrixKit &out_kit) const
	Shows the net modelling matrix attribute settings along this key path. More...
bool	ShowNetTextureMatrix (MatrixKit &out_kit) const
	Shows the net texture matrix attribute settings along this key path. More...
bool	ShowNetCulling (CullingKit &out_kit) const
	Shows the net culling attribute settings along this key path. More...
bool	ShowNetTransparency (TransparencyKit &out_kit) const
	Shows the net transparency attribute settings along this key path. More...
bool	ShowNetTransformMask (TransformMaskKit &out_kit) const
	Shows the net transform mask attribute settings along this key path. More...
bool	ShowNetMaterialMapping (MaterialMappingKit &out_kit) const
	Shows the net material mapping attribute settings along this key path. More...
bool	ShowNetNURBSSurfaceAttribute (NURBSSurfaceAttributeKit &out_kit) const
	Shows the net NURBS surface attribute settings along this key path. More...
bool	ShowNetVisualEffects (VisualEffectsKit &out_kit) const
	Shows the net visual effects attribute settings along this key path. More...
bool	ShowNetSubwindow (SubwindowKit &out_kit) const
	Shows the net subwindow attribute settings along this key path. More...
bool	ShowNetAttributeLock (AttributeLockKit &out_kit) const
	Shows the net attribute lock settings along this key path. More...
bool	ShowNetConditions (UTF8Array &out_conditions) const
	Shows the net condition settings along this key path. More...
size_t	GatherCutGeometry (SegmentKey const &in_destination, CutGeometryGatheringOptionsKit const &in_options) const
	Collects capping geometry generated by cutting planes. More...
bool	ShowNetClipRegions (PointArrayArrayArray &out_loops_array, ClipSpaceArray &out_spaces, ClipOperationArray &out_operations, MatrixKitArray &out_matrices) const
	Collects all clip regions on key path. More...
bool	ShowNetMaterialPalette (UTF8 &out_name) const
	Shows the material palette name along this key path. More...
bool	ShowEffectiveMaterialPaletteDefinition (char const *in_name, MaterialPaletteDefinition &out_def) const
	Shows the effective material palette definition belonging to the input name along this key path. More...
bool	ShowEffectiveGlyphDefinition (char const *in_name, GlyphDefinition &out_def) const
	Shows the effective glyph definition belonging to the input name along this key path. More...
bool	ShowEffectiveLinePatternDefinition (char const *in_name, LinePatternDefinition &out_def) const
	Shows the effective line pattern definition belonging to the input name along this key path. More...
bool	ShowEffectiveShaderDefinition (char const *in_name, ShaderDefinition &out_def) const
	Shows the effective shader definition belonging to the input name along this key path. More...
bool	ShowEffectiveTextureDefinition (char const *in_name, TextureDefinition &out_def) const
	Shows the effective texture definition belonging to the input name along this key path. More...
bool	ShowEffectiveImageDefinition (char const *in_name, ImageDefinition &out_def) const
	Shows the effective image definition belonging to the input name along this key path. More...
virtual HPS::Type	Type () const
	This function returns the true type of the underlying object. More...
virtual bool	Empty () const
	Indicates whether this object has any values set on it. More...
virtual void	Reset ()
	Resets this object to its initial, uninitialized state. More...
bool	HasType (HPS::Type in_mask) const
	This function indicates whether this Object has the given Type mask. More...
intptr_t	GetClassID () const
	Returns a unique identifier that is shared by all objects of the same class. More...
intptr_t	GetInstanceID () const
	Returns an identifier that can be used to identify which instance of a class an object is. More...

Static Public Member Functions
template<typename T >
static intptr_t	ClassID ()
	Unique identifier for this class. More...

Static Public Attributes
static const HPS::Type	staticType = HPS::Type::KeyPath

Detailed Description

The KeyPath contains an array of keys, organized from leaf to root.

It allows the user to perform a number of queries along that path including accumulating net attributes and converting coordinates.

Constructor & Destructor Documentation

KeyPath() [1/5]

HPS::KeyPath::KeyPath

(

)

Creates an uninitialized key path that refers to no database objects.

KeyPath() [2/5]

HPS::KeyPath::KeyPath

(

KeyArray const &

in_path

)

Creates a new KeyPath object based on the supplied path.

Parameters

in_path

An array of keys arranged from leaf to root.

KeyPath() [3/5]

HPS::KeyPath::KeyPath	(	size_t	in_path_count,
		Key const	in_path[]
	)

Creates a new KeyPath object based on the supplied path.

Parameters

in_path_count	The number of keys in the array.
in_path	An array of keys arranged from leaf to root.

KeyPath() [4/5]

HPS::KeyPath::KeyPath

(

KeyPath const &

in_that

)

Copies in_that into this key path.

KeyPath() [5/5]

HPS::KeyPath::KeyPath

(

KeyPath &&

in_that

)

The move constructor creates a KeyPath by transferring the underlying impl of the rvalue reference to this KeyPath thereby avoiding a copy and allocation.

Parameters

in_that

An rvalue reference to a KeyPath to take the impl from.

~KeyPath()

virtual HPS::KeyPath::~KeyPath ( )

virtual

Releases a reference to the database object this object is tied to.

Member Function Documentation

Append() [1/3]

KeyPath& HPS::KeyPath::Append

(

Key const &

in_key

)

Appends the supplied Key into this object.

Same as operator+= function.

Parameters

in_key

The Key to be appended to this.

Returns

A reference to this object.

Append() [2/3]

KeyPath& HPS::KeyPath::Append

(

KeyPath const &

in_key_path

)

Appends the supplied key into this object.

Same as operator+= function.

Parameters

in_key_path

The KeyPath to be appended to this.

Returns

A reference to this object.

Append() [3/3]

KeyPath& HPS::KeyPath::Append

(

KeyArray const &

in_key_array

)

Appends the supplied key into this object.

Same as operator+= function.

Parameters

in_key_array

The KeyArray to be appended to this.

Returns

A reference to this object.

ClassID()

template<typename T >

static intptr_t HPS::Object::ClassID ( )

inlinestaticinherited

Unique identifier for this class.

Note: this method uses construction of static objects. If used in a constructor, it should be used in the body not the initializer list.

ComputeExtent() [1/4]

bool HPS::KeyPath::ComputeExtent

(

Rectangle &

out_extent

)

const

Computes a tight 2D extents box around the geometry contained in this key path.

A user can use this information to tightly fit a camera to a specified segment or draw a 2D box around the segment. The coordinates are returned to the user in screen space.

Parameters

out_extent

The screen extent of the geometry under this key path.

Returns

true if the operation succeeded, false otherwise.

ComputeExtent() [2/4]

bool HPS::KeyPath::ComputeExtent	(	HPS::VisibilityKit const &	in_vis,
		Rectangle &	out_extent
	)		const

Computes a tight 2D extents box around the geometry contained in this key path.

A user can use this information to tightly fit a camera to a specified segment or draw a 2D box around the segment. The coordinates are returned to the user in screen space.

Parameters

in_vis	Explicit visibility settings to acknowledge instead of using the visibilities resolved by this key path.
out_extent	The screen extent of the geometry under this key path.

Returns

true if the operation succeeded, false otherwise.

ComputeExtent() [3/4]

bool HPS::KeyPath::ComputeExtent	(	HPS::Extent::ClipRegion	in_clip,
		Rectangle &	out_extent
	)		const

Computes a tight 2D extents box around the geometry contained in this key path.

A user can use this information to tightly fit a camera to a specified segment or draw a 2D box around the segment. The coordinates are returned to the user in screen space.

Parameters

in_clip	The setting which indicates whether clip regions should be ignored or included.
out_extent	The screen extent of the geometry under this key path.

Returns

true if the operation succeeded, false otherwise.

ComputeExtent() [4/4]

bool HPS::KeyPath::ComputeExtent	(	HPS::VisibilityKit const &	in_vis,
		HPS::Extent::ClipRegion	in_clip,
		Rectangle &	out_extent
	)		const

Computes a tight 2D extents box around the geometry contained in this key path.

A user can use this information to tightly fit a camera to a specified segment or draw a 2D box around the segment. The coordinates are returned to the user in screen space.

Parameters

in_vis	Explicit visibility settings to acknowledge instead of using the visibilities resolved by this key path.
in_clip	The setting which indicates whether clip regions should be ignored or included.
out_extent	The screen extent of the geometry under this key path.

Returns

true if the operation succeeded, false otherwise.

ComputeTextExtent()

bool HPS::KeyPath::ComputeTextExtent	(	char const *	in_text,
		float &	out_xfrac,
		float &	out_yfrac
	)		const

Computes the extents of the specified text string based on the effective text attributes along this key path.

If the effective text transform setting is Text::Transform::Transformable, the returned values will be in object space units. For any other effective text transform setting, the returned values will be a fraction of the segment window from 0.0 to 1.0 (or more) along this key path.

Parameters

in_text	The text to measure along this keypath
out_xfrac	The width of the text extent
out_yfrac	The height of the text extent

Returns

true if the operation succeeded, false otherwise.

ComputeTransform()

bool HPS::KeyPath::ComputeTransform	(	Coordinate::Space	in_space,
		Coordinate::Space	in_output_space,
		HPS::MatrixKit &	out_matrix
	)		const

Computes the matrix which transforms objects from the input space to the output space along this key path.

Parameters

in_space	The starting or input coordinate space.
in_output_space	The final or output coordinate space.
out_matrix	The matrix which transforms objects from the input space to the output space.

Returns

true if the operation succeeded, false otherwise.

ConvertCoordinate() [1/2]

bool HPS::KeyPath::ConvertCoordinate	(	Coordinate::Space	in_space,
		Point const &	in_point,
		Coordinate::Space	in_output_space,
		Point &	out_point
	)		const

Converts a point from one coordinate space to another using the transforms along this key path.

Parameters

in_space	The coordinate space of the input point.
in_point	The input point to convert.
in_output_space	The coordinate space to convert the input point into.
out_point	The output point, after conversion.

Returns

true if the operation succeeded, false otherwise.

ConvertCoordinate() [2/2]

bool HPS::KeyPath::ConvertCoordinate	(	Coordinate::Space	in_space,
		PointArray const &	in_points,
		Coordinate::Space	in_output_space,
		PointArray &	out_points
	)		const

Converts a point from one coordinate space to another using the transforms along this key path.

Parameters

in_space	The coordinate space of the input point.
in_points	The input points to convert.
in_output_space	The coordinate space to convert the input point into.
out_points	The output points, after conversion.

Returns

true if the operation succeeded, false otherwise.

Empty()

virtual bool HPS::Object::Empty ( ) const

inlinevirtualinherited

Indicates whether this object has any values set on it.

Returns

true if no values are set on this object, false otherwise.

Reimplemented in HPS::STL::ImportResultsKit, HPS::STL::ImportOptionsKit, HPS::OBJ::ImportResultsKit, HPS::OBJ::ImportOptionsKit, HPS::Hardcopy::File::ExportOptionsKit, HPS::Stream::ExportOptionsKit, HPS::Stream::ImportResultsKit, HPS::Stream::ImportOptionsKit, HPS::PointCloud::ImportOptionsKit, HPS::PointCloud::ImportResultsKit, HPS::UpdateOptionsKit, HPS::HighlightSearchOptionsKit, HPS::HighlightOptionsKit, HPS::SelectionOptionsKit, HPS::SearchOptionsKit, HPS::CutGeometryGatheringOptionsKit, HPS::ShapeKit, HPS::ShaderKit, HPS::Shader::ImportOptionsKit, HPS::ImageKit, HPS::Image::ImportOptionsKit, HPS::Image::ExportOptionsKit, HPS::TextureOptionsKit, HPS::LinePatternKit, HPS::LinePatternParallelKit, HPS::LinePatternOptionsKit, HPS::GlyphKit, HPS::ApplicationWindowOptionsKit, HPS::OffScreenWindowOptionsKit, HPS::StandAloneWindowOptionsKit, HPS::GridKit, HPS::PolygonKit, HPS::MeshKit, HPS::ShellKit, HPS::ShellRelationResultsKit, HPS::ShellRelationOptionsKit, HPS::ShellOptimizationOptionsKit, HPS::TextKit, HPS::EllipticalArcKit, HPS::EllipseKit, HPS::TrimKit, HPS::NURBSSurfaceKit, HPS::NURBSCurveKit, HPS::SpotlightKit, HPS::InfiniteLineKit, HPS::CuttingSectionKit, HPS::CircularWedgeKit, HPS::CircularArcKit, HPS::CircleKit, HPS::SphereKit, HPS::CylinderKit, HPS::DistantLightKit, HPS::MarkerKit, HPS::LineKit, HPS::AttributeLockKit, HPS::FontInfoState, HPS::WindowInfoKit, HPS::DebuggingKit, HPS::SubwindowKit, HPS::ContourLineKit, HPS::VisualEffectsKit, HPS::TransformMaskKit, HPS::PostProcessEffectsKit, HPS::DrawingAttributeKit, HPS::HiddenLineAttributeKit, HPS::PerformanceKit, HPS::NURBSSurfaceAttributeKit, HPS::MaterialKit, HPS::MaterialMappingKit, HPS::MatrixKit, HPS::CurveAttributeKit, HPS::EdgeAttributeKit, HPS::LineAttributeKit, HPS::TextAttributeKit, HPS::CuttingSectionAttributeKit, HPS::CylinderAttributeKit, HPS::LightingAttributeKit, HPS::SphereAttributeKit, HPS::MarkerAttributeKit, HPS::CullingKit, HPS::ColorInterpolationKit, HPS::TransparencyKit, HPS::SelectabilityKit, HPS::CameraKit, HPS::VisibilityKit, HPS::BoundingKit, HPS::SegmentOptimizationOptionsKit, HPS::Publish::ExportOptionsKit, HPS::Publish::TextFieldKit, HPS::Publish::SignatureFieldKit, HPS::Publish::DropDownListKit, HPS::Exchange::TessellationOptionsKit, HPS::Publish::ListBoxKit, HPS::Exchange::ExportSTEPOptionsKit, HPS::Exchange::ExportParasolidOptionsKit, HPS::Publish::RadioButtonKit, HPS::Exchange::ExportIGESOptionsKit, HPS::Exchange::ExportXMLOptionsKit, HPS::Publish::CheckBoxKit, HPS::Exchange::ExportU3DOptionsKit, HPS::Exchange::ExportSTLOptionsKit, HPS::Publish::ButtonKit, HPS::Exchange::ExportPRCOptionsKit, HPS::Publish::LinkKit, HPS::Exchange::ExportJTOptionsKit, HPS::Publish::SlideTableKit, HPS::Exchange::ExportACISOptionsKit, HPS::Publish::TableKit, HPS::Exchange::Export3MFOptionsKit, HPS::Publish::ImageKit, HPS::Publish::TextKit, HPS::Exchange::ModelFileImportOptionsKit, HPS::Publish::ViewKit, HPS::Exchange::TranslationOptionsKit, HPS::Publish::ArtworkKit, HPS::Publish::AnnotationKit, HPS::ComponentPath, HPS::Exchange::ImportOptionsKit, HPS::Parasolid::ExportOptionsKit, HPS::Exchange::NURBSConversionOptionsKit, HPS::Parasolid::LineTessellationKit, HPS::Exchange::Configuration, HPS::Publish::PageKit, HPS::Parasolid::FacetTessellationKit, HPS::Publish::DocumentKit, HPS::Parasolid::ImportOptionsKit, HPS::DWG::ImportOptionsKit, HPS::OOC::ImportOptionsKit, HPS::Sketchup::ImportOptionsKit, and HPS::Sketchup::ImportResultsKit.

Equals()

bool HPS::KeyPath::Equals

(

KeyPath const &

in_that

)

const

Check if the source KeyPath is equivalent to this object.

Parameters

in_that

The source KeyPath to compare to this object.

Returns

true if the objects are equivalent, false otherwise.

GatherCutGeometry()

size_t HPS::KeyPath::GatherCutGeometry	(	SegmentKey const &	in_destination,
		CutGeometryGatheringOptionsKit const &	in_options
	)		const

Collects capping geometry generated by cutting planes.

Geometry is deposited in the segment you specify. Note: Capping geometry is generated during an update. Until an update is completed, no geometry will be present to gather.

Parameters

in_destination	A segment that the capping geometry will be deposited into.
in_options	Options for the gathering operation.

Returns

The number of individual caps created.

GetClassID()

intptr_t HPS::Object::GetClassID ( ) const

inherited

Returns a unique identifier that is shared by all objects of the same class.

Returns

A unique value shared by all objects of the same class.

GetInstanceID()

intptr_t HPS::Object::GetInstanceID ( ) const

inherited

Returns an identifier that can be used to identify which instance of a class an object is.

Different keys and controls will return the same value if they are backed by the same database resource.

Returns

A value unique to an instance of an object and all objects that are backed by the same database resource.

HasType()

bool HPS::Object::HasType ( HPS::Type  in_mask ) const

inherited

This function indicates whether this Object has the given Type mask.

Parameters

in_mask

The Type mask to check against this Object.

Returns

true if this Object has the given Type mask, false otherwise.

ObjectType()

HPS::Type HPS::KeyPath::ObjectType ( ) const

inlinevirtual

Reimplemented from HPS::Object.

Here is the call graph for this function:

operator!=()

bool HPS::KeyPath::operator!=

(

KeyPath const &

in_that

)

const

Check if the source KeyPath is not equivalent to this object.

Parameters

in_that

The source KeyPath to compare to this object.

Returns

true if the objects are not equivalent, false otherwise.

operator+=() [1/3]

KeyPath& HPS::KeyPath::operator+=

(

Key const &

in_key

)

Appends the supplied Key into this object.

Same as Append function.

Parameters

in_key

The key to be appended to this.

Returns

A reference to this object.

operator+=() [2/3]

KeyPath& HPS::KeyPath::operator+=

(

KeyPath const &

in_key_path

)

Appends the supplied KeyPath into this object.

Same as Append function.

Parameters

in_key_path

The KeyPath to be appended to this.

Returns

A reference to this object.

operator+=() [3/3]

KeyPath& HPS::KeyPath::operator+=

(

KeyArray const &

in_key_array

)

Appends the supplied KeyArray into this object.

Same as Append function.

Parameters

in_key_array

The KeyArray to be appended to this.

Returns

A reference to this object.

operator=() [1/3]

KeyPath& HPS::KeyPath::operator=

(

KeyPath &&

in_that

)

The move assignment operator transfers the underlying impl of the rvalue reference to this KeyPath thereby avoiding a copy.

Parameters

in_that

An rvalue reference to a KeyPath to take the impl from.

Returns

A reference to this KeyPath.

operator=() [2/3]

KeyPath& HPS::KeyPath::operator=

(

KeyPath const &

in_that

)

Copies the supplied path into this object.

Parameters

in_that

The source of the copy.

Returns

A reference to this object.

operator=() [3/3]

KeyPath& HPS::KeyPath::operator=

(

KeyArray const &

in_path

)

Copies an array of keys into this object.

Parameters

in_path

The source array, assumed to be arranged from leaf to root.

Returns

A reference to this object.

operator==()

bool HPS::KeyPath::operator==

(

KeyPath const &

in_that

)

const

Check if the source KeyPath is equivalent to this object.

Parameters

in_that

The source KeyPath to compare to this object.

Returns

true if the objects are equivalent, false otherwise.

Reset()

virtual void HPS::Object::Reset ( )

virtualinherited

Resets this object to its initial, uninitialized state.

Reimplemented in HPS::EventHandler, HPS::EventDispatcher, HPS::World, HPS::HighlightSearchResults, HPS::HighlightSearchResultsIterator, HPS::SelectionResults, HPS::SelectionResultsIterator, HPS::FontSearchResults, HPS::FontSearchResultsIterator, HPS::SearchResults, and HPS::SearchResultsIterator.

Set()

void HPS::KeyPath::Set

(

KeyPath const &

in_that

)

Copies the supplied path into this object.

Parameters

in_that

The source of the copy.

SetKeys() [1/2]

KeyPath& HPS::KeyPath::SetKeys

(

KeyArray const &

in_keys

)

Copies an array of keys into this object.

Parameters

in_keys

The source array, assumed to be arranged from leaf to root.

Returns

A reference to this object.

SetKeys() [2/2]

KeyPath& HPS::KeyPath::SetKeys	(	size_t	in_key_count,
		Key const	in_keys[]
	)

Copies an array of keys into this object.

Parameters

in_key_count	the number of keys in the array.
in_keys	The source array, assumed to arranged from leaf to root.

Returns

A reference to this object.

ShowEffectiveGlyphDefinition()

bool HPS::KeyPath::ShowEffectiveGlyphDefinition	(	char const *	in_name,
		GlyphDefinition &	out_def
	)		const

Shows the effective glyph definition belonging to the input name along this key path.

Parameters

in_name	UTF8-encoded name of the glyph to find along this key path.
out_def	The effective glyph definition, if any, with the specified name along this key path.

Returns

true if the glyph definition exists along this path, false otherwise.

ShowEffectiveImageDefinition()

bool HPS::KeyPath::ShowEffectiveImageDefinition	(	char const *	in_name,
		ImageDefinition &	out_def
	)		const

Shows the effective image definition belonging to the input name along this key path.

Parameters

in_name	UTF8-encoded name of the image to find along this key path.
out_def	The effective image definition, if any, with the specified name along this key path.

Returns

true if the image definition exists along this path, false otherwise.

ShowEffectiveLinePatternDefinition()

bool HPS::KeyPath::ShowEffectiveLinePatternDefinition	(	char const *	in_name,
		LinePatternDefinition &	out_def
	)		const

Shows the effective line pattern definition belonging to the input name along this key path.

Parameters

in_name	UTF8-encoded name of the line pattern to find along this key path.
out_def	The effective material line pattern, if any, with the specified name along this key path.

Returns

true if the line pattern definition exists along this path, false otherwise.

ShowEffectiveMaterialPaletteDefinition()

bool HPS::KeyPath::ShowEffectiveMaterialPaletteDefinition	(	char const *	in_name,
		MaterialPaletteDefinition &	out_def
	)		const

Shows the effective material palette definition belonging to the input name along this key path.

Parameters

in_name	UTF8-encoded name of the material palette to find along this key path.
out_def	The effective material palette definition, if any, with the specified name along this key path.

Returns

true if the material palette definition exists along this path, false otherwise.

ShowEffectiveShaderDefinition()

bool HPS::KeyPath::ShowEffectiveShaderDefinition	(	char const *	in_name,
		ShaderDefinition &	out_def
	)		const

Shows the effective shader definition belonging to the input name along this key path.

Parameters

in_name	UTF8-encoded name of the shader to find along this key path.
out_def	The effective shader definition, if any, with the specified name along this key path.

Returns

true if the shader definition exists along this path, false otherwise.

ShowEffectiveTextureDefinition()

bool HPS::KeyPath::ShowEffectiveTextureDefinition	(	char const *	in_name,
		TextureDefinition &	out_def
	)		const

Shows the effective texture definition belonging to the input name along this key path.

Parameters

in_name	UTF8-encoded name of the texture to find along this key path.
out_def	The effective texture definition, if any, with the specified name along this key path.

Returns

true if the texture definition exists along this path, false otherwise.

ShowKeys()

bool HPS::KeyPath::ShowKeys

(

KeyArray &

out_keys

)

const

Shows the keys defining this key path.

Returns

true if the setting is valid, false otherwise.

ShowNetAttributeLock()

bool HPS::KeyPath::ShowNetAttributeLock

(

AttributeLockKit &

out_kit

)

const

Shows the net attribute lock settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetBounding()

bool HPS::KeyPath::ShowNetBounding

(

BoundingKit &

out_kit

)

const

Shows the net bounding along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetCamera()

bool HPS::KeyPath::ShowNetCamera

(

CameraKit &

out_kit

)

const

Shows the net camera attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetClipRegions()

bool HPS::KeyPath::ShowNetClipRegions	(	PointArrayArrayArray &	out_loops_array,
		ClipSpaceArray &	out_spaces,
		ClipOperationArray &	out_operations,
		MatrixKitArray &	out_matrices
	)		const

Collects all clip regions on key path.

Parameters

out_loops_array	An array of arrays of loops describing the clip region.
out_spaces	An array of the coordinate spaces in which loops are described.
out_operations	An array of the operations performed by the clip regions.
out_matrices	An array of the matrices used by the clip regions if they are in ClipSpace::Object else identity matrix.

Returns

true if clip regions exist along this path, false otherwise.

ShowNetColorInterpolation()

bool HPS::KeyPath::ShowNetColorInterpolation

(

ColorInterpolationKit &

out_kit

)

const

Shows the net color interpolation attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetConditions()

bool HPS::KeyPath::ShowNetConditions

(

UTF8Array &

out_conditions

)

const

Shows the net condition settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetContourLine()

bool HPS::KeyPath::ShowNetContourLine

(

ContourLineKit &

out_kit

)

const

Shows the net contour line attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetCulling()

bool HPS::KeyPath::ShowNetCulling

(

CullingKit &

out_kit

)

const

Shows the net culling attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetCurveAttribute()

bool HPS::KeyPath::ShowNetCurveAttribute

(

CurveAttributeKit &

out_kit

)

const

Shows the net curve attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetCuttingSectionAttribute()

bool HPS::KeyPath::ShowNetCuttingSectionAttribute

(

CuttingSectionAttributeKit &

out_kit

)

const

Shows the net cutting section attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetCylinderAttribute()

bool HPS::KeyPath::ShowNetCylinderAttribute

(

CylinderAttributeKit &

out_kit

)

const

Shows the net cylinder attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetDrawingAttribute()

bool HPS::KeyPath::ShowNetDrawingAttribute

(

DrawingAttributeKit &

out_kit

)

const

Shows the net drawing attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetEdgeAttribute()

bool HPS::KeyPath::ShowNetEdgeAttribute

(

EdgeAttributeKit &

out_kit

)

const

Shows the net edge attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetHiddenLineAttribute()

bool HPS::KeyPath::ShowNetHiddenLineAttribute

(

HiddenLineAttributeKit &

out_kit

)

const

Shows the net hidden line attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetLightingAttribute()

bool HPS::KeyPath::ShowNetLightingAttribute

(

LightingAttributeKit &

out_kit

)

const

Shows the net lighting attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetLineAttribute()

bool HPS::KeyPath::ShowNetLineAttribute

(

LineAttributeKit &

out_kit

)

const

Shows the net line attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetMarkerAttribute()

bool HPS::KeyPath::ShowNetMarkerAttribute

(

MarkerAttributeKit &

out_kit

)

const

Shows the net marker attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetMaterialMapping()

bool HPS::KeyPath::ShowNetMaterialMapping

(

MaterialMappingKit &

out_kit

)

const

Shows the net material mapping attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetMaterialPalette()

bool HPS::KeyPath::ShowNetMaterialPalette

(

UTF8 &

out_name

)

const

Shows the material palette name along this key path.

Returns

true if a material palette is set along this path, false otherwise.

ShowNetModellingMatrix()

bool HPS::KeyPath::ShowNetModellingMatrix

(

MatrixKit &

out_kit

)

const

Shows the net modelling matrix attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetNURBSSurfaceAttribute()

bool HPS::KeyPath::ShowNetNURBSSurfaceAttribute

(

NURBSSurfaceAttributeKit &

out_kit

)

const

Shows the net NURBS surface attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetPerformance()

bool HPS::KeyPath::ShowNetPerformance

(

PerformanceKit &

out_kit

)

const

Shows the net performance attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetSelectability()

bool HPS::KeyPath::ShowNetSelectability

(

SelectabilityKit &

out_kit

)

const

Shows the net selectability attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetSphereAttribute()

bool HPS::KeyPath::ShowNetSphereAttribute

(

SphereAttributeKit &

out_kit

)

const

Shows the net sphere attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetSubwindow()

bool HPS::KeyPath::ShowNetSubwindow

(

SubwindowKit &

out_kit

)

const

Shows the net subwindow attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetTextAttribute()

bool HPS::KeyPath::ShowNetTextAttribute

(

TextAttributeKit &

out_kit

)

const

Shows the net text attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetTextureMatrix()

bool HPS::KeyPath::ShowNetTextureMatrix

(

MatrixKit &

out_kit

)

const

Shows the net texture matrix attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetTransformMask()

bool HPS::KeyPath::ShowNetTransformMask

(

TransformMaskKit &

out_kit

)

const

Shows the net transform mask attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetTransparency()

bool HPS::KeyPath::ShowNetTransparency

(

TransparencyKit &

out_kit

)

const

Shows the net transparency attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetVisibility()

bool HPS::KeyPath::ShowNetVisibility

(

VisibilityKit &

out_kit

)

const

Shows the net visibility attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

ShowNetVisualEffects()

bool HPS::KeyPath::ShowNetVisualEffects

(

VisualEffectsKit &

out_kit

)

const

Shows the net visual effects attribute settings along this key path.

Returns

true if the setting is valid along this path, false otherwise.

Type()

virtual HPS::Type HPS::Object::Type ( ) const

virtualinherited

This function returns the true type of the underlying object.

This function is useful for finding the type of smart pointer objects that have been cast to more generic types.

Returns

The true type of the object in question.

Reimplemented in HPS::UpdateOptionsControl, HPS::HighlightControl, HPS::SelectionOptionsControl, HPS::OffScreenWindowOptionsControl, HPS::ApplicationWindowOptionsControl, HPS::StandAloneWindowOptionsControl, HPS::AttributeLockControl, HPS::WindowInfoControl, HPS::DebuggingControl, HPS::SubwindowControl, HPS::ContourLineControl, HPS::VisualEffectsControl, HPS::TransformMaskControl, HPS::PostProcessEffectsControl, HPS::DrawingAttributeControl, HPS::HiddenLineAttributeControl, HPS::PerformanceControl, HPS::NURBSSurfaceAttributeControl, HPS::ConditionControl, HPS::StyleControl, HPS::PortfolioControl, HPS::MaterialMappingControl, HPS::TextureMatrixControl, HPS::ModellingMatrixControl, HPS::CurveAttributeControl, HPS::EdgeAttributeControl, HPS::LineAttributeControl, HPS::TextAttributeControl, HPS::CuttingSectionAttributeControl, HPS::CylinderAttributeControl, HPS::LightingAttributeControl, HPS::SphereAttributeControl, HPS::MarkerAttributeControl, HPS::CullingControl, HPS::ColorInterpolationControl, HPS::TransparencyControl, HPS::SelectabilityControl, HPS::CameraControl, HPS::VisibilityControl, HPS::BoundingControl, HPS::Kit, and HPS::Control.

UnsetKeys()

KeyPath& HPS::KeyPath::UnsetKeys

(

)

Removes the keys defining this key path.

Returns

A reference to this object.

Member Data Documentation

staticType

const HPS::Type HPS::KeyPath::staticType = HPS::Type::KeyPath

static

---

The documentation for this class was generated from the following file:

• hps.h
